Snap Ring Groove Ball Bearings 214 NR

Snap Ring Groove Ball Bearings 214 NR

The 214 NR is a snap ring groove ball bearing with a 70mm bore and 125mm outer diameter, crafted from sturdy chrome steel for reliable performance. Its compact width of 24mm makes it suitable for tight spaces while handling radial loads up to 14837 lbf.

The open design ensures easy lubrication, and the stainless steel cage enhances durability. With a maximum speed of 5600 RPM, it operates smoothly in temperatures ranging from -30°C to 120°C.

The snap ring on the outer ring provides secure positioning, ideal for applications where axial movement needs to be restricted. This bearing is interchangeable with SKF models, offering a practical replacement option.

Weighing 1.15kg, it’s robust yet manageable for industrial machinery or automotive applications. Compliant with REACH standards, it’s a safe choice for various environments.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 214 NR
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 125 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 24 mm
  • Width Tolerance -0.15mm to 0
  • Outside Diameter Of Snap Ring 134.7 mm
  • Width Of Snap Ring 2.82 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 14837 lbf
  • Static Radial Load 14725 lbf
  • Temperature Range -30° to 120 °C
  • REACH Compliant
  • Max Speed 5600 rpm
  • Weight 1.15 kg
Snap Ring Groove Ball Bearings 214 NR dimension drawing
Download DWG Download PDF

Features

How Does 214 NR Bearing Ensure Smooth Radial Load Handling?

214 NR Bearing features chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 14837 lbf, making it suitable for demanding applications.

The stainless steel cage maintains ball alignment, reducing friction and wear.
With a maximum speed of 5,600 rpm, it delivers reliable performance under various conditions.

214 NR Bearing’s snap ring design simplifies installation and enhances stability.
Its temperature range of -30° to 120°C ensures adaptability in different environments.

Application

Industrial Uses of 214 NR Bearing
214 NR Bearing is commonly used in machine tools and conveyor systems, where its snap ring groove ensures secure outer ring positioning. The open design allows for easy lubrication, making it suitable for high-speed operations.

Where Is 214 NR Bearing Used?
You’ll find 214 NR Bearing in automotive gearboxes and electric motors, where its radial load capacity handles constant motion. The chrome steel construction provides durability in these demanding applications.

Built for Heavy-Duty Use: 214 NR Bearing
214 NR Bearing excels in industrial fans and pumps, thanks to its stainless steel cage that resists wear. The metric sizing makes it a versatile choice for European machinery standards.

Automotive vs Industrial: Applications of 214 NR Bearing
In vehicles, 214 NR Bearing supports wheel hubs and transmissions, while in factories it powers conveyor rollers. Its snap ring feature simplifies installation in both settings.

Perfect Fit for Automation: 214 NR Bearing
214 NR Bearing works well in robotic arms and assembly lines, where precision and reliability are key. The P0 tolerance class ensures consistent performance in automated processes.
