SKF INSOCOAT Cylindrical Roller Bearings NU 1012 ML/C3VL0241

SKF INSOCOAT Cylindrical Roller Bearings NU 1012 ML/C3VL0241

The SKF INSOCOAT bearing is a cylindrical roller type measuring 60mm by 95mm by 18mm, with a robust machined brass cage. It handles dynamic loads up to 340 kN and spins smoothly at reference speeds of 4800 RPM.
Its key feature is an insulating coating on the outer ring, which provides protection against electrical currents. This helps prevent damage in electrically noisy environments, ensuring reliable operation.
With a breakdown voltage rating from 1000 to 3000 VDC, it suits motors and generators where electrical insulation is needed. The C3 radial clearance accommodates thermal expansion in various conditions.
Weighing 0.48 kg, it’s a practical choice for industrial machinery. Compliant with RoHS and REACH standards, it offers a dependable solution for demanding applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NU 1012 ML/C3VL0241
  • Product Category INSOCOAT Cylindrical Roller Bearings
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix VL0241
  • Manufacturers SKF
  • Bore Diameter 60.0 mm
  • Outside Diameter 95.0 mm
  • Width 18.0 mm
  • Net Weight 0.48 kg
  • Basic Dynamic Load Rating 340.0 kN
  • Basic Static Load Rating 335.0 kN
  • Reference Speed 4800.0r/min
  • Breakdown Voltage (DC) 1000 VDC to 3000 VDC
  • Layer Thic kNess 500 µm
  • Electrical Resistance Min. 50MΩ
  • Cage Material Machined brass
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
SKF INSOCOAT Cylindrical Roller Bearings NU 1012 ML/C3VL0241 dimension drawing
Download DWG Download PDF

Features

How Is NU 1012 ML/C3VL0241 Bearing Engineered for Reliability?

NU 1012 ML/C3VL0241 Bearing features an insulation coating on its outer ring, protecting against electrical damage in demanding applications.
This coating provides a breakdown voltage ranging from 1000 to 3000 VDC, ensuring reliable operation in electrically hazardous environments.
With a basic dynamic load rating of 340 kN, it handles heavy radial loads while maintaining stable performance.
The machined brass cage keeps rollers properly aligned, reducing wear and extending service life.

Application

How Does NU 1012 ML/C3VL0241 Bearing Improve Performance?
NU 1012 ML/C3VL0241 Bearing works well in industrial machinery like machine tools and conveyor systems, where its cylindrical roller design handles radial loads effectively.
The insulation coating helps prevent electrical damage in motor applications, making it suitable for use in various manufacturing environments.

In automotive applications, NU 1012 ML/C3VL0241 Bearing can be found in gearboxes and electric motor systems, providing reliable performance under different operating conditions.
Its brass cage and C3 clearance allow for thermal expansion, which helps maintain stability in vehicle components.

For medical equipment such as imaging devices and laboratory instruments, NU 1012 ML/C3VL0241 Bearing offers consistent operation due to its precise dimensions and insulation properties.
The coating reduces the risk of electrical currents affecting sensitive medical devices, ensuring they function properly during procedures.

In automation and robotics, NU 1012 ML/C3VL0241 Bearing supports robotic arms and automated assembly lines by managing loads smoothly.
Its design contributes to reduced maintenance needs, which is beneficial in high-use industrial settings.
