SKF INSOCOAT Bearings 6322M/C4VL0241

SKF INSOCOAT Bearings 6322M/C4VL0241

The SKF INSOCOAT bearing 6322M/C4VL0241 measures 110mm by 240mm by 50mm, with a robust brass cage and insulation coating on the outer ring. It handles dynamic loads up to 216 kN and spins smoothly at speeds of 6000 RPM.

The insulating coating provides protection against electrical currents, with a breakdown voltage of up to 3000V and resistance of 200 MΩ. Its C4 radial clearance ensures reliable performance in high-temperature or high-speed conditions.

Weighing 10.9kg, this bearing is built for durability in demanding environments. Ideal for electric motors or generators where insulation is needed to prevent damage from stray currents.

Compliant with RoHS standards, it’s a safe and efficient choice for industrial applications. The VL0241 coating suffix ensures easy identification for replacements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model 6322M/C4VL0241
  • Product Category INSOCOAT Bearings
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix VL0241
  • Manufacturers SKF
  • Bore Diameter 110.0 mm
  • Outside Diameter 240.0 mm
  • Width 50.0 mm
  • Net Weight 10.9kg
  • Basic Dynamic Load Rating 216.0 kN
  • Basic Static Load Rating 180.0 kN
  • Reference Speed 6000.0 r/min
  • Breakdown Voltage (DC) ≤3000 V
  • Layer Thickness 500 µm
  • Electrical Resistance 200 MΩ
  • Cage Material Brass cage
  • Radial Internal Clearance C4
  • ROHS Compliant
  • REACH Compliant
SKF INSOCOAT Bearings 6322M/C4VL0241 dimension drawing
Download DWG Download PDF

Features

How Is 6322M/C4VL0241 Bearing Engineered for Reliability?

6322M/C4VL0241 Bearing features an insulation coating on the outer ring, protecting against electrical currents and extending its lifespan.
The brass cage ensures smooth operation, even at high speeds up to 6,000 r/min.
With a basic dynamic load rating of 216 kN, it handles heavy loads reliably.
Its breakdown voltage of up to 3,000 V makes it suitable for electrically demanding environments.

Application

Industrial Uses of 6322M/C4VL0241 Bearing
This bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical arcing. The brass cage ensures smooth operation even at high speeds.

Where Is 6322M/C4VL0241 Bearing Used?
You’ll find 6322M/C4VL0241 Bearing in wind turbines, where it handles heavy loads and resists electrical damage. Its C4 clearance makes it suitable for thermal expansion in demanding environments.

Built for Heavy-Duty Use: 6322M/C4VL0241 Bearing
In industrial pumps, 6322M/C4VL0241 Bearing offers reliable performance with its high dynamic load rating. The insulation coating also makes it ideal for applications with variable frequencies.

Automotive vs Aerospace: Applications of 6322M/C4VL0241 Bearing
While 6322M/C4VL0241 Bearing isn’t typically used in aerospace, it’s great for automotive alternators due to its insulation properties. The high reference speed ensures efficiency in vehicle systems.

Perfect Fit for Automation: 6322M/C4VL0241 Bearing
In automated machinery, 6322M/C4VL0241 Bearing reduces downtime with its durable design. The coating also protects against stray currents in sensitive equipment.
