SKF INSOCOAT Bearings 6312M/C3VL0241

SKF INSOCOAT Bearings 6312M/C3VL0241

The SKF INSOCOAT 6312M/C3VL0241 is a robust bearing with a 60mm bore and 130mm outer diameter, featuring an insulating coating on the outer ring. It handles dynamic loads up to 85.2 kN and spins smoothly at speeds up to 11000 RPM.

The brass cage ensures durability, while the C3 radial clearance allows for thermal expansion. The insulation coating provides protection against electrical currents, with a breakdown voltage of up to 3000V.

This bearing is ideal for electric motors or generators where electrical insulation is needed. Its compact size (31mm width) and 1.9kg weight make it easy to integrate into various setups.

Compliant with RoHS standards, it’s a reliable choice for industrial applications requiring both mechanical and electrical performance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model 6312M/C3VL0241
  • Product Category INSOCOAT Bearings
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix VL0241
  • Manufacturers SKF
  • Bore Diameter 60.0 mm
  • Outside Diameter 130.0 mm
  • Width 31.0 mm
  • Net Weight 1.9 kg
  • Basic Dynamic Load Rating 85.2 kN
  • Basic Static Load Rating 52.0 kN
  • Reference Speed 11000 r/min
  • Breakdown Voltage (DC) ≤3000 V
  • Layer Thickness 500 µm
  • Electrical Resistance 200 MΩ
  • Cage Material Brass cage
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
SKF INSOCOAT Bearings 6312M/C3VL0241 dimension drawing
Download DWG Download PDF

Features

How Is 6312M/C3VL0241 Bearing Engineered for Reliability?

6312M/C3VL0241 Bearing features an insulation coating on the outer ring, providing protection against electrical currents.
The brass cage ensures smooth operation and reduces friction, even at high speeds up to 11,000 r/min.
With a basic dynamic load rating of 85.2 kN, it handles heavy loads reliably.
Its C3 radial internal clearance allows for thermal expansion, making it suitable for varied operating conditions.

Application

Industrial Uses of 6312M/C3VL0241 Bearing
This bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical damage from stray currents. The brass cage ensures smooth operation even at high speeds.

Where Is 6312M/C3VL0241 Bearing Used?
You’ll find 6312M/C3VL0241 Bearing in wind turbines, where its high dynamic load rating handles the demanding conditions. The C3 clearance allows for thermal expansion in these variable environments.

Built for Heavy-Duty Use: 6312M/C3VL0241 Bearing
In industrial pumps, 6312M/C3VL0241 Bearing’s insulation coating protects against electrical corrosion. Its 500 µm layer thickness ensures long-term reliability in harsh conditions.

Automotive vs Aerospace: Applications of 6312M/C3VL0241 Bearing
While 6312M/C3VL0241 Bearing suits hybrid vehicle motors, its high-speed capability also makes it ideal for aerospace actuators. The breakdown voltage rating adds safety in both applications.

Perfect Fit for Automation: 6312M/C3VL0241 Bearing
This bearing works well in robotic arms, where its low electrical resistance prevents static buildup. The 31 mm width fits neatly into compact automation designs.
