Single Row Deep Groove Ball Bearings With Filling Slots 207/C3

Single Row Deep Groove Ball Bearings With Filling Slots 207/C3

The 207/C3 is a single-row deep groove ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 6182 lbf and operates smoothly at speeds up to 10,000 RPM.

Its open design with filling slots allows for easy lubrication, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 0.31kg, it offers a balance of strength and lightweight design. Compliant with REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 207/C3
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Grade No C3
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 6182 lbf
  • Static Radial Load 4946 lbf
  • Temperature Range -30°to 120 °C
  • REACH Compliant
  • Max Speed 10000 rpm
  • Weight 0.31 kg
  • Price（$） 10.02
Single Row Deep Groove Ball Bearings With Filling Slots 207/C3 dimension drawing
Download DWG Download PDF

Features

Why Choose 207/C3 Bearing for Precision Tasks?

207/C3 Bearing features a single row deep groove design with filling slots, enhancing its radial load capacity.
Its chrome steel construction ensures durability and resistance to wear in various applications.

The bearing’s dynamic radial load capacity of 6182 lbf makes it suitable for high-performance machinery.
With a maximum speed of 10,000 rpm, it delivers reliable and efficient operation.

207/C3 Bearing operates in temperatures ranging from -30°C to 120°C, adapting to diverse working conditions.
Its open seal type allows for easy maintenance and lubrication, reducing downtime.

Application

Industrial Uses of 207/C3 Bearing
The 207/C3 Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. Its open construction allows for easy lubrication, extending service life in demanding conditions.

In automotive applications, 207/C3 Bearing fits well in components such as alternators and wheel hubs, providing reliable performance under varying speeds. The C3 clearance ensures smooth operation even with thermal expansion.

For automation systems, 207/C3 Bearing supports robotic arms and conveyor belts, where precision and durability are key. Its chrome steel construction offers good resistance to wear in continuous operation.

Where Is 207/C3 Bearing Used?
You’ll often find 207/C3 Bearing in household appliances like washing machines, where its quiet operation and load capacity are appreciated. The metric sizing makes it compatible with many European-designed products.

In light industrial equipment, 207/C3 Bearing works well in gearboxes and small machinery, balancing performance and cost. Its filling slots simplify maintenance, reducing downtime in production environments.
