Single Row Deep Groove Ball Bearings RLS 9-2RS1

Single Row Deep Groove Ball Bearings RLS 9-2RS1

The RLS 9-2RS1 is a sealed single-row deep groove ball bearing with a 1.125″ bore and 2.5″ outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 4564 lbf and runs smoothly at speeds up to 7500 RPM.

Its sealed design keeps grease in and dirt out, reducing maintenance needs. The stainless steel cage adds durability, making it a reliable choice for long-term use. It operates well in temperatures from -30°C to 120°C.

This bearing is interchangeable with SKF models, offering a practical replacement option. Ideal for applications like electric motors or small machinery where radial loads and sealed protection are key.

Weighing 0.23kg, it’s compact yet robust. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number RLS 9-2RS1
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Inch
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 1.125"
  • Bore Dia Tolerance -0.00031" to 0.00019"
  • Outer Dia 2.5"
  • Outer Dia Tolerance -0.00098" to -0.00051"
  • Width 0.625"
  • Width Tolerance -0.005" to 0"
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 4564 lbf
  • Static Radial Load 2518 lbf
  • Max Speed 7500 rpm
  • Weight 0.23 kg
  • price（$） 12.654
Single Row Deep Groove Ball Bearings RLS 9-2RS1 dimension drawing
Download DWG Download PDF

Features

Why Choose RLS 9-2RS1 Bearing for Precision Tasks?

RLS 9-2RS1 Bearing features a sealed design, protecting against contaminants and ensuring smooth operation.

Its chrome steel construction provides excellent resistance to wear, making it suitable for radial load applications.

With a dynamic radial load capacity of 4564 lbf, it handles demanding tasks with ease.

The grease lubrication reduces maintenance needs, while the P6 tolerance class ensures high precision.

Application

Industrial Uses of RLS 9-2RS1 Bearing
RLS 9-2RS1 Bearing is commonly used in conveyor systems and industrial fans, where its sealed design keeps out dust and debris. The chrome steel construction ensures it can handle radial loads with ease.

Where Is RLS 9-2RS1 Bearing Used?
In automotive applications, RLS 9-2RS1 Bearing fits well in electric motors and pumps, providing smooth operation. Its grease lubrication reduces maintenance needs, making it ideal for long-term use.

Built for Heavy-Duty Use: RLS 9-2RS1 Bearing
For automation equipment like robotic arms, RLS 9-2RS1 Bearing offers reliable performance with its stainless steel cage. The P6 tolerance class ensures precision in high-speed operations.

Light-Duty vs Heavy-Duty: Best Uses for RLS 9-2RS1 Bearing
In household appliances such as washing machines, RLS 9-2RS1 Bearing provides quiet and efficient performance. Its sealed design also makes it suitable for environments where moisture is a concern.
