Single Row Deep Groove Ball Bearings 6908-VAL

Single Row Deep Groove Ball Bearings 6908-VAL

The 6908-VAL is a single-row deep groove ball bearing with a 40mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3082 lbf and spins efficiently at speeds up to 13,000 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing operates smoothly in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a dependable option for replacements. Perfect for applications like electric motors or small machinery where radial loads are typical.

Weighing just 131g, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6908-VAL
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 12 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3082 lbf
  • Static Radial Load 2232 lbf
  • Max Speed 13000 rpm
  • Weight 131 g
  • price（$） 14.553
Single Row Deep Groove Ball Bearings 6908-VAL dimension drawing
Download DWG Download PDF

Features

Performance Features of 6908-VAL Bearing

6908-VAL Bearing is constructed with chrome steel rings and balls, offering reliable radial load support.
Its dynamic radial load capacity reaches 3082 lbf, making it suitable for various applications.

The open design of 6908-VAL Bearing allows for easy lubrication and maintenance.
With a maximum speed of 13,000 rpm, it ensures smooth operation in high-speed conditions.

6908-VAL Bearing operates efficiently in temperatures ranging from -30°C to 120°C.
Its durable chrome steel cage enhances stability and extends the bearing’s service life.

Application

Common Applications of 6908-VAL Bearing
In industrial settings, 6908-VAL Bearing is a go-to for radial load support in machinery like pumps and electric motors. Its open design and chrome steel construction ensure reliable performance in demanding environments.

Where Is 6908-VAL Bearing Used?
You’ll often spot 6908-VAL Bearing in automotive applications, such as alternators and small gearboxes, where its compact size and radial load capacity shine. The ABEC 1 tolerance makes it a cost-effective choice for standard precision needs.

Built for Heavy-Duty Use: 6908-VAL Bearing
For automation equipment like conveyor belts, 6908-VAL Bearing handles continuous operation with ease. Its high-speed capability (up to 13,000 rpm) and temperature resistance make it versatile for various industrial tasks.

Medical vs Industrial: Where 6908-VAL Bearing Excels
In medical devices like centrifuges, 6908-VAL Bearing offers quiet and smooth rotation. Meanwhile, in industrial fans, its durability and load capacity keep systems running efficiently.

Perfect Fit for Automation: 6908-VAL Bearing
6908-VAL Bearing works well in robotic arms and small automation systems, thanks to its lightweight design and radial load handling. The chrome steel cage adds extra durability for long-term use.
