Single Row Deep Groove Ball Bearings 6407/W64

Single Row Deep Groove Ball Bearings 6407/W64

The 6407/W64 is a single-row deep groove ball bearing with a 35mm bore and 100mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 12432 lbf and operates smoothly at speeds up to 7000 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 950g, it offers a robust build for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6407/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 25 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 12432 lbf
  • Static Radial Load 6969 lbf
  • Max Speed 7000 rpm
  • Weight 950 g
Single Row Deep Groove Ball Bearings 6407/W64 dimension drawing
Download DWG Download PDF

Features

Built for Reliability: 6407/W64 Bearing

6407/W64 Bearing features a single-row deep groove design, optimised for radial load handling with a dynamic capacity of 12,432 lbf.
Its chrome steel construction ensures durability and resistance to wear in various applications.

The open seal design allows for easy maintenance while the solid oil lubrication reduces friction.
With a maximum speed of 7,000 rpm, it delivers consistent performance under demanding conditions.

6407/W64 Bearing operates efficiently within a temperature range of -30°C to 120°C.
Its ABEC 1 tolerance class ensures reliable precision for general industrial use.

Application

Common Applications of 6407/W64 Bearing
The 6407/W64 Bearing is widely used in industrial machinery, such as pumps and electric motors, where its deep groove design handles radial loads efficiently. Its open seal type simplifies lubrication and maintenance in dusty environments.

In automotive applications, 6407/W64 Bearing fits well in wheel hubs and alternators, providing reliable performance under varying speeds. The chrome steel construction ensures durability even in demanding driving conditions.

For automation systems, 6407/W64 Bearing supports robotic arms and conveyor belts, offering smooth rotation with minimal friction. The solid oil lubrication extends service life, reducing downtime in continuous operations.

Household appliances like washing machines often use 6407/W64 Bearing for its quiet operation and resistance to wear. Its metric sizing makes it compatible with many standard designs.
