Single Row Deep Groove Ball Bearings 6316-Z/C3S1

Single Row Deep Groove Ball Bearings 6316-Z/C3S1

The 6316-Z/C3S1 is a single-row deep groove ball bearing with an 80mm bore and 170mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 27652 lbf and operates smoothly at speeds up to 4000 RPM.

Its shielded design offers basic protection against dust and debris, while the C3 radial clearance ensures reliable performance under varying temperatures. The bearing works well in environments ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads are common.

Weighing 3670g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6316-Z/C3S1
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 80 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 170 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 39 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 200 °C
  • Dynamic Radial Load 27652 lbf
  • Static Radial Load 19491 lbf
  • Max Speed 4000 rpm
  • Weight 3670 g
  • price（$） 50.283
Single Row Deep Groove Ball Bearings 6316-Z/C3S1 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6316-Z/C3S1 Bearing

6316-Z/C3S1 Bearing is built with chrome steel rings and balls, offering strong radial load capacity.
Its dynamic radial load reaches 27652 lbf, making it suitable for demanding applications.

The shielded design protects against contaminants, ensuring smooth operation in various environments.
With a maximum speed of 4,000 rpm, it balances performance and durability.

6316-Z/C3S1 Bearing operates in temperatures from -30° to 200°C, adapting to diverse conditions.
Its C3 clearance provides optimal performance under thermal expansion and heavy loads.

The chrome steel cage maintains ball alignment, reducing wear and extending service life.
This design ensures reliable performance with minimal maintenance requirements.

Application

Industrial Uses of 6316-Z/C3S1 Bearing
6316-Z/C3S1 Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The C3 radial clearance ensures smooth operation even under varying thermal conditions.

Where Is 6316-Z/C3S1 Bearing Used?
You’ll often find 6316-Z/C3S1 Bearing in automotive applications such as wheel hubs and transmissions, thanks to its robust chrome steel construction. Its metric sizing makes it a versatile fit for many European and Asian vehicle models.

Perfect Fit for Automation: 6316-Z/C3S1 Bearing
6316-Z/C3S1 Bearing works well in automated systems like conveyor belts, where consistent radial load handling is key. The ABEC 1 tolerance ensures reliable performance without unnecessary complexity.

Medical vs Industrial: Where 6316-Z/C3S1 Bearing Excels
In medical devices like centrifuges, 6316-Z/C3S1 Bearing offers quiet and reliable operation. For industrial gearboxes, its high dynamic load capacity makes it a dependable choice.

Light-Duty vs Heavy-Duty: Best Uses for 6316-Z/C3S1 Bearing
6316-Z/C3S1 Bearing handles light-duty tasks in household appliances like washing machines with ease. In heavier industrial settings, it supports equipment like compressors without faltering.
