Single Row Deep Groove Ball Bearings 6313 MC/P52

Single Row Deep Groove Ball Bearings 6313 MC/P52

The 6313 MC/P52 is a single-row deep groove ball bearing with a 65mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 2084 lbf and operates smoothly at speeds up to 4800 RPM.

Its open design and machined metal cage ensure durability, while the ABEC 5 tolerance class offers precise performance. The bearing works reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads are common.

Weighing 2080g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6313 MC/P52
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 5 | ISO P5
  • Radial Clearance Trade No CN
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 33 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Machined metal
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2084 lbf
  • Static Radial Load 13466 lbf
  • Max Speed 4800 rpm
  • Weight 2080 g
  • price（$） 158.85
Single Row Deep Groove Ball Bearings 6313 MC/P52 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6313 MC/P52 Bearing

6313 MC/P52 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 2084 lbf, ensuring reliable performance in various applications.

The machined metal cage maintains ball alignment, reducing friction and enhancing durability.
With a maximum speed of 4,800 rpm, it balances efficiency and long service life.

6313 MC/P52 Bearing operates smoothly in temperatures from -30°C to 120°C, suitable for diverse environments.
Its precision ABEC 5 | ISO P5 tolerance ensures consistent performance in demanding conditions.

Application

Industrial Uses of 6313 MC/P52 Bearing
6313 MC/P52 Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The ABEC 5 precision ensures smooth operation in high-performance environments.

In automotive applications, 6313 MC/P52 Bearing fits well in wheel hubs and transmissions, offering reliable performance under varying speeds. Its chrome steel construction provides durability against wear and tear.

For automation systems, 6313 MC/P52 Bearing supports robotic arms and conveyor belts, ensuring precise movement. The open seal design allows for easy lubrication, extending its service life.

Medical equipment benefits from 6313 MC/P52 Bearing’s precision, particularly in imaging devices where consistent rotation is key. The machined metal cage adds stability during prolonged use.

Household appliances like washing machines often use 6313 MC/P52 Bearing for its quiet operation and long-lasting performance. Its metric sizing makes it a versatile choice for various models.
