Single Row Deep Groove Ball Bearings 6312 M/C3VL0241

Single Row Deep Groove Ball Bearings 6312 M/C3VL0241

The 6312 M/C3VL0241 is a single row deep groove ball bearing with a 60mm bore and 130mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 18412 lbf and operates smoothly at speeds up to 5300 RPM.

Its open design allows for easy lubrication, while the machined metal cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 1699g, it offers a robust build for industrial use. Compliant with RoHS and REACH standards for safe and eco-friendly operation.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6312 M/C3VL0241
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 130 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 31 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Machined metal
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 18412 lbf
  • Static Radial Load 11735 lbf
  • Max Speed 5300 rpm
  • Weight 1699 g
  • price（$） 167.67
Single Row Deep Groove Ball Bearings 6312 M/C3VL0241 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6312 M/C3VL0241 Bearing

6312 M/C3VL0241 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 18412 lbf.
Its machined metal cage ensures precise ball alignment, enhancing durability and smooth operation.

The C3 radial clearance allows for thermal expansion, making it suitable for varied temperature conditions.
With a maximum speed of 5,300 rpm, it balances performance and reliability in demanding applications.

6312 M/C3VL0241 Bearing operates efficiently within a temperature range of -30° to 120°C.
Its open design simplifies maintenance while ensuring consistent performance over time.

Application

Industrial Uses of 6312 M/C3VL0241 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in demanding conditions.

What Makes 6312 M/C3VL0241 Bearing a Preferred Choice?
Its chrome steel construction ensures durability in automotive applications such as wheel hubs and transmissions. The C3 clearance also accommodates thermal expansion, making it reliable under varying temperatures.

Perfect Fit for Automation: 6312 M/C3VL0241 Bearing
In robotic arms and conveyor systems, this bearing offers smooth rotation and low friction. The machined metal cage provides added stability, essential for precision movements in automated setups.

Medical vs Industrial: Where 6312 M/C3VL0241 Bearing Excels
While it’s robust enough for heavy machinery, its precision also suits medical devices like centrifuges. The ISO P0 tolerance ensures consistent performance in both high-speed and high-precision environments.
