Single Row Deep Groove Ball Bearings 6312/C3W64

Single Row Deep Groove Ball Bearings 6312/C3W64

The 6312/C3W64 is a single-row deep groove ball bearing with a 60mm bore and 130mm outer diameter, crafted from sturdy chrome steel for lasting durability. It manages radial loads up to 18412 lbf and operates smoothly at speeds up to 5300 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage enhances reliability. The bearing performs well in temperatures ranging from -30°C to 120°C.

With a C3 radial clearance, it’s suitable for applications where slight expansion or misalignment might occur. Ideal for use in electric motors, pumps, or industrial gearboxes.

Weighing 1699g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, making it a safe and dependable choice.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6312/C3W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 130 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 31 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 18412 lbf
  • Static Radial Load 11735 lbf
  • Max Speed 5300 rpm
  • Weight 1699 g
Single Row Deep Groove Ball Bearings 6312/C3W64 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6312/C3W64 Bearing

6312/C3W64 Bearing is designed with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 18412 lbf, ensuring reliable performance in various applications.
The chrome steel cage maintains ball alignment, reducing wear and extending service life.
With a maximum speed of 5,300 rpm, it balances durability and efficiency.

Application

Industrial Uses of 6312/C3W64 Bearing
6312/C3W64 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The solid oil lubrication extends service life, reducing maintenance needs in demanding environments.

Where Is 6312/C3W64 Bearing Used?
You’ll often find 6312/C3W64 Bearing in automotive applications such as wheel hubs and transmissions, thanks to its durable chrome steel construction. Its C3 clearance also accommodates thermal expansion, making it suitable for varying operating conditions.

Perfect Fit for Automation: 6312/C3W64 Bearing
In robotic arms and automated conveyor systems, 6312/C3W64 Bearing provides smooth rotation and consistent performance. The open design allows for easy inspection and lubrication, ideal for high-use settings.

Medical vs Industrial: Where 6312/C3W64 Bearing Excels
While 6312/C3W64 Bearing handles heavy loads in industrial gearboxes, it’s also found in medical devices like centrifuges. Its temperature range and solid oil lubrication make it versatile across different sectors.
