Single Row Deep Groove Ball Bearings 6312/C3S0

Single Row Deep Groove Ball Bearings 6312/C3S0

The 6312/C3S0 is a single row deep groove ball bearing with a 60mm bore and 130mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 18412 lbf and operates smoothly at speeds up to 5300 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 150°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 1699g, it offers a robust build for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6312/C3S0
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 130 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 31 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 150 °C
  • Dynamic Radial Load 18412 lbf
  • Static Radial Load 11735 lbf
  • Max Speed 5300 rpm
  • Weight 1699 g
  • price（$） 35.901
Single Row Deep Groove Ball Bearings 6312/C3S0 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6312/C3S0 Bearing

6312/C3S0 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 18412 lbf.
Its C3 radial clearance ensures smooth operation even under varying temperatures.
The open design allows for easy lubrication, enhancing performance in diverse conditions.
With a maximum speed of 5,300 rpm, it balances durability and efficiency in demanding applications.

Application

Industrial Uses of 6312/C3S0 Bearing
6312/C3S0 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending its service life in demanding conditions.

In automotive applications, 6312/C3S0 Bearing fits well in wheel hubs and transmissions, providing smooth rotation under heavy loads. Its C3 clearance accommodates thermal expansion, making it suitable for high-temperature environments.

For automation systems, 6312/C3S0 Bearing supports robotic arms and conveyor belts, offering stability and precision. The chrome steel construction ensures durability, even in continuous operation scenarios.

Where Is 6312/C3S0 Bearing Used?
You’ll find 6312/C3S0 Bearing in household appliances like washing machines, where its quiet operation and durability are key. The metric sizing makes it a versatile choice for various European and Asian brands.

Built for Heavy-Duty Use: 6312/C3S0 Bearing
6312/C3S0 Bearing handles radial loads effortlessly in construction equipment like gearboxes and compressors. Its robust chrome steel rings and balls withstand harsh conditions without compromising performance.
