Single Row Deep Groove Ball Bearings 6312-2RSH

Single Row Deep Groove Ball Bearings 6312-2RSH

The 6312-2RSH is a single-row deep groove ball bearing with a 60mm bore and 130mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 19154 lbf and runs smoothly at speeds up to 3400 RPM.

Sealed on both sides, it keeps grease in and dirt out, making it low-maintenance. The stainless steel cage adds durability, while the P6 tolerance ensures precise performance.

Suitable for temperatures from -30°C to 120°C, it’s a reliable choice for industrial machinery or electric motors. Weighing 1.76kg, it’s robust yet manageable for its size.

Compliant with RoHS and REACH standards, it’s interchangeable with SKF bearings for easy replacements. Ideal for applications needing long-lasting, sealed performance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6312-2RSH
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 130 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 31 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 19154 lbf
  • Static Radial Load 11690 lbf
  • Max Speed 3400 rpm
  • Weight 1.76 kg
Single Row Deep Groove Ball Bearings 6312-2RSH dimension drawing
Download DWG Download PDF

Features

Why Choose 6312-2RSH Bearing for Precision Tasks?

6312-2RSH Bearing features a sealed design, keeping contaminants out and ensuring smooth operation.
Its chrome steel construction provides excellent durability and resistance to wear.

The single row deep groove design allows for high radial load capacity, up to 19154 lbf.
With a maximum speed of 3,400 rpm, it balances performance and reliability.

6312-2RSH Bearing operates efficiently in temperatures ranging from -30° to 120°C.
Its stainless steel cage maintains ball alignment, reducing friction and extending lifespan.

Application

Industrial Uses of 6312-2RSH Bearing
6312-2RSH Bearing is commonly used in industrial machinery like pumps and electric motors, where its sealed design keeps contaminants out. The chrome steel construction ensures durability even in demanding environments.

Where Is 6312-2RSH Bearing Used?
In automotive applications, 6312-2RSH Bearing fits well in wheel hubs and transmissions, providing reliable radial load support. Its grease lubrication reduces maintenance needs, making it a practical choice for long-term use.

Perfect Fit for Automation: 6312-2RSH Bearing
For automation systems, 6312-2RSH Bearing works smoothly in conveyor belts and robotic arms. The stainless steel cage adds extra resistance to wear, ensuring consistent performance over time.

Light-Duty vs Heavy-Duty: Best Uses for 6312-2RSH Bearing
In light-duty applications like household appliances, 6312-2RSH Bearing offers quiet operation and efficiency. For heavier tasks, its dynamic load capacity makes it suitable for industrial gearboxes and machinery.
