Single Row Deep Groove Ball Bearings 6311 M/C3VL0241

Single Row Deep Groove Ball Bearings 6311 M/C3VL0241

The 6311 M/C3VL0241 is a single-row deep groove ball bearing with a 55mm bore and 120mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 16658 lbf and operates smoothly at speeds up to 11000 RPM.

Its open design allows for easy lubrication, while the machined metal cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 1.65kg, it offers a robust build for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6311 M/C3VL0241
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 29 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Machined metal
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 16658 lbf
  • Static Radial Load 10116 lbf
  • Max Speed 11000 rpm
  • Weight 1.65 kg
  • price（$） 161.991
Single Row Deep Groove Ball Bearings 6311 M/C3VL0241 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6311 M/C3VL0241 Bearing

6311 M/C3VL0241 Bearing is built with chrome steel rings and balls, offering excellent radial load capacity up to 16658 lbf.
Its machined metal cage ensures smooth operation and reduces friction during high-speed rotation.

The C3 radial clearance allows for thermal expansion, making it suitable for varying temperatures from -30°C to 120°C.
This design ensures reliable performance in diverse operating conditions.

With a maximum speed of 11,000 rpm, 6311 M/C3VL0241 Bearing balances speed and durability.
Its open seal type simplifies maintenance while keeping operational costs low.

The precision-engineered dimensions (55 mm×120 mm×29 mm) ensure easy installation and compatibility.
This makes 6311 M/C3VL0241 Bearing a practical choice for various industrial applications.

Application

Industrial Uses of 6311 M/C3VL0241 Bearing
6311 M/C3VL0241 Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in demanding environments.

Where Is 6311 M/C3VL0241 Bearing Used?
You’ll find 6311 M/C3VL0241 Bearing in automotive applications such as wheel hubs and transmissions, thanks to its robust chrome steel construction. Its C3 clearance ensures reliable performance even under varying thermal conditions.

Built for Heavy-Duty Use: 6311 M/C3VL0241 Bearing
6311 M/C3VL0241 Bearing excels in conveyor systems and agricultural equipment, where its machined metal cage provides added durability. The ABEC 1 tolerance makes it a dependable choice for general industrial use.

Automotive vs Industrial: Applications of 6311 M/C3VL0241 Bearing
In automotive settings, 6311 M/C3VL0241 Bearing supports smooth rotation in drivetrains, while in industrial gearboxes, it handles high radial loads with ease. Its wide temperature range suits both indoor and outdoor applications.
