Single Row Deep Groove Ball Bearings 6310-2Z/C3GJN

The 6310-2Z/C3GJN is a single-row deep groove ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 13938 lbf and operates smoothly at speeds up to 6000 RPM.

Shielded on both sides, it keeps dirt out while maintaining smooth rotation. The C3 radial clearance ensures reliable performance under varying temperatures, from -30°C to 120°C.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. It’s well-suited for electric motors, pumps, or industrial gearboxes where radial loads are common.

Weighing 1050g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s safe for various applications.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6310-2Z/C3GJN
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Shielded
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No C3
Bore Dia 50 mm
Bore Dia Tolerance -0.012mm to 0
Outer Dia 110 mm
Outer Dia Tolerance -0.015mm to 0
Width 27 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 13938 lbf
Static Radial Load 861 lbf
Max Speed 6000 rpm
Weight 1050 g
price（$） 13.599

Single Row Deep Groove Ball Bearings 6310-2Z/C3GJN dimension drawing

Download DWG Download PDF

Features

Performance Features of 6310-2Z/C3GJN Bearing

6310-2Z/C3GJN Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 13,938 lbf, ensuring reliable performance in various applications.

The shielded design of 6310-2Z/C3GJN Bearing protects against contaminants, extending its service life.
With a maximum speed of 6,000 rpm, it balances durability and efficiency for smooth operation.

6310-2Z/C3GJN Bearing operates in temperatures from -30°C to 120°C, making it versatile for different environments.
Its C3 radial clearance provides optimal performance under varying thermal conditions.

The chrome steel cage ensures proper ball alignment, reducing wear and maintenance needs.
This design makes 6310-2Z/C3GJN Bearing a cost-effective choice for long-term use.

Application

Industrial Uses of 6310-2Z/C3GJN Bearing
6310-2Z/C3GJN Bearing is commonly used in conveyor systems and industrial fans, where its shielded design helps keep contaminants out. The C3 radial clearance ensures smooth operation even under varying thermal conditions.

Where Is 6310-2Z/C3GJN Bearing Used?
In automotive applications, 6310-2Z/C3GJN Bearing fits well in electric motors and pumps, thanks to its balanced radial load capacity. The chrome steel construction offers durability in high-speed scenarios.

Built for Heavy-Duty Use: 6310-2Z/C3GJN Bearing
For automation equipment like robotic arms, 6310-2Z/C3GJN Bearing provides reliable performance with minimal maintenance. Its metric sizing makes it easy to integrate into various machinery designs.

Light-Duty vs Heavy-Duty: Best Uses for 6310-2Z/C3GJN Bearing
In household appliances such as washing machines, 6310-2Z/C3GJN Bearing ensures quiet and efficient operation. The shielded seals protect against dust and moisture, extending its lifespan.
