Single Row Deep Groove Ball Bearings 6310-2Z/C2ELHT23

Single Row Deep Groove Ball Bearings 6310-2Z/C2ELHT23

The 6310-2Z/C2ELHT23 is a single-row deep groove ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 13938 lbf and operates smoothly at speeds up to 6000 RPM.

Its shielded design keeps out dust and debris, while the C2 radial clearance ensures reliable performance under varying temperatures (-30°C to 120°C). The chrome steel cage adds durability for long-term use.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where consistent radial load handling is needed.

Weighing 1050g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6310-2Z/C2ELHT23
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C2
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 27 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 13938 lbf
  • Static Radial Load 861 lbf
  • Max Speed 6000 rpm
  • Weight 1050 g
  • price（$） 14.877
Single Row Deep Groove Ball Bearings 6310-2Z/C2ELHT23 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6310-2Z/C2ELHT23 Bearing

6310-2Z/C2ELHT23 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 13,938 lbf.
Its shielded design helps keep contaminants out, ensuring smoother operation in various conditions.

The C2 radial clearance provides optimal performance, balancing flexibility and precision.
With a maximum speed of 6,000 rpm, it delivers reliable efficiency for industrial applications.

Its temperature range of -30°C to 120°C makes it suitable for diverse environments.
The chrome steel cage enhances durability, reducing wear over extended use.

Application

Industrial Uses of 6310-2Z/C2ELHT23 Bearing
6310-2Z/C2ELHT23 Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability even in demanding environments.

In automotive applications, 6310-2Z/C2ELHT23 Bearing fits well in wheel hubs and transmissions, providing reliable radial load support. Its C2 clearance allows for slight thermal expansion, making it suitable for varying temperatures.

For automation systems, 6310-2Z/C2ELHT23 Bearing works efficiently in robotic arms and conveyor belts. The metric sizing ensures compatibility with a wide range of equipment, while the ABEC 1 tolerance offers consistent performance.

In household appliances like washing machines, 6310-2Z/C2ELHT23 Bearing ensures smooth operation with minimal maintenance. The shielded seals help prolong its lifespan by preventing dust and moisture ingress.

Medical devices such as centrifuges benefit from 6310-2Z/C2ELHT23 Bearing’s reliable performance. The chrome steel balls and cage provide smooth rotation, essential for precision equipment.
