Single Row Deep Groove Ball Bearings 6306 TC/C78

Single Row Deep Groove Ball Bearings 6306 TC/C78

The 6306 TC/C78 is a single-row deep groove ball bearing with a 30mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 6002 lbf and spins smoothly at speeds up to 9600 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing operates well in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads are common.

Weighing 346g, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6306 TC/C78
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 19 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6002 lbf
  • Static Radial Load 3372 lbf
  • Max Speed 9600 rpm
  • Weight 346 g
  • price（$） 73.215
Single Row Deep Groove Ball Bearings 6306 TC/C78 dimension drawing
Download DWG Download PDF

Features

How Does 6306 TC/C78 Bearing Reduce Friction?

6306 TC/C78 Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
Its chrome steel construction ensures durability while minimising friction during operation.

The open seal type allows for easy maintenance, making it suitable for various industrial applications.
With a maximum speed of 9,600 rpm, it delivers reliable performance under demanding conditions.

Engineered to ABEC 1 standards, 6306 TC/C78 Bearing maintains precision even at high speeds.
Its temperature range of -30°C to 120°C ensures adaptability in diverse environments.

Application

Industrial Uses of 6306 TC/C78 Bearing
The 6306 TC/C78 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. Its open design allows for easy lubrication, making it suitable for continuous operation.

In automotive applications, 6306 TC/C78 Bearing supports components such as alternators and wheel hubs, providing smooth rotation under varying loads. The chrome steel construction enhances durability, even in demanding driving conditions.

For automation systems, 6306 TC/C78 Bearing is a practical choice for robotic arms and conveyor belts, thanks to its balanced load handling. The ABEC 1 tolerance ensures consistent performance in precision-driven tasks.

Where Is 6306 TC/C78 Bearing Used?
You’ll often find 6306 TC/C78 Bearing in household appliances like washing machines and fans, where its quiet operation is a plus. The metric sizing makes it compatible with a wide range of consumer products.

Built for Heavy-Duty Use: 6306 TC/C78 Bearing
The 6306 TC/C78 Bearing handles radial loads effortlessly in construction equipment like small gearboxes. Its chrome steel cage adds extra resilience, making it ideal for rugged environments.
