Single Row Deep Groove Ball Bearings 608-2RSL/C3LHT23

Single Row Deep Groove Ball Bearings 608-2RSL/C3LHT23

The 608-2RSL/C3LHT23 is a compact single-row deep groove ball bearing with an 8mm bore and 22mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 630 lbf and spins smoothly at speeds up to 34,000 RPM.

Its sealed design keeps dirt out and grease in, making it low-maintenance, while the C3 clearance allows for slight thermal expansion. The bearing operates reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative. Perfect for small motors, skateboards, or inline skates where smooth rotation is key.

Weighing just 11.8g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 608-2RSL/C3LHT23
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 8 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 22 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 630 lbf
  • Static Radial Load 248 lbf
  • Max Speed 34000 rpm
  • Weight 11.8 g
  • price（$） 1.863
Single Row Deep Groove Ball Bearings 608-2RSL/C3LHT23 dimension drawing
Download DWG Download PDF

Features

How Does 608-2RSL/C3LHT23 Bearing Reduce Friction?

608-2RSL/C3LHT23 Bearing features a single-row deep groove design, optimised for smooth radial load handling.
Its chrome steel construction ensures durability while reducing friction during operation.
The sealed design protects against contaminants, maintaining performance in various environments.
With a maximum speed of 34,000 rpm, it offers reliable efficiency for high-speed applications.

Application

Common Applications of 608-2RSL/C3LHT23 Bearing
You’ll often spot 608-2RSL/C3LHT23 Bearing in skateboards and inline skates, where its compact size and smooth rotation keep wheels spinning effortlessly. The sealed design helps keep dirt out, making it ideal for outdoor use.

In small electric motors, 608-2RSL/C3LHT23 Bearing handles radial loads reliably, whether in power tools or household appliances. Its chrome steel construction ensures durability even with frequent starts and stops.

For office equipment like printers, 608-2RSL/C3LHT23 Bearing’s low noise operation keeps things running quietly. The C3 clearance provides just enough play for thermal expansion during continuous use.

Where Is 608-2RSL/C3LHT23 Bearing Used?
608-2RSL/C3LHT23 Bearing pops up in fitness equipment too, supporting pulley systems in home gyms with its consistent performance. The wide temperature range means it won’t falter during intense workouts.

You’ll also find 608-2RSL/C3LHT23 Bearing in model-making and DIY projects where small, reliable bearings are needed. Its metric sizing makes it compatible with many European-designed mechanisms.

Built for Versatility: 608-2RSL/C3LHT23 Bearing
In conveyor systems for light packaging, 608-2RSL/C3LHT23 Bearing keeps rollers moving smoothly. The sealed design protects against dust in warehouse environments.

For small robotics joints, 608-2RSL/C3LHT23 Bearing offers just the right balance of size and load capacity. Its high-speed capability suits precise, repetitive movements perfectly.

Light-Duty vs Heavy-Duty: Best Uses for 608-2RSL/C3LHT23 Bearing
While 608-2RSL/C3LHT23 Bearing shines in light applications like fidget spinners, it’s equally at home in small industrial fans. The chrome steel balls handle continuous rotation without wearing quickly.

In camera gimbals and stabilizers, 608-2RSL/C3LHT23 Bearing provides the smooth motion needed for steady shots. Its lightweight design won’t add unnecessary bulk to portable gear.
