Single Row Deep Groove Ball Bearings 6305/C5

Single Row Deep Groove Ball Bearings 6305/C5

The 6305/C5 is a single-row deep groove ball bearing with a 25mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 4631 lbf and operates smoothly at speeds up to 11000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

With a C5 radial clearance, it offers flexibility for applications with slight misalignments. This model is interchangeable with SKF bearings, making it a practical choice for replacements.

Ideal for use in electric motors, pumps, or machinery where radial load support is needed. Weighing 232g, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6305/C5
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C5
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4631 lbf
  • Static Radial Load 254 lbf
  • Max Speed 11000 rpm
  • Weight 232 g
  • price（$） 6.264
Single Row Deep Groove Ball Bearings 6305/C5 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6305/C5 Bearing

6305/C5 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 4631 lbf.
Its single-row deep groove design ensures smooth operation, making it suitable for various applications.

The C5 radial clearance provides flexibility in high-speed operations, reaching up to 11,000 rpm.
With a temperature range of -30°C to 120°C, it performs reliably in diverse environments.

6305/C5 Bearing’s open design simplifies maintenance, while its chrome steel cage enhances durability.
Its metric dimensions (25 mm×62 mm×17 mm) ensure compatibility with standard systems.

Application

Industrial Uses of 6305/C5 Bearing
The 6305/C5 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. Its open design allows for easy lubrication, extending service life in demanding conditions.

What Makes 6305/C5 Bearing a Preferred Choice?
In automotive applications, 6305/C5 Bearing supports components such as alternators and water pumps, thanks to its balanced radial load handling. The C5 clearance provides optimal performance in high-temperature environments.

Perfect Fit for Automation: 6305/C5 Bearing
For robotic arms and conveyor systems, 6305/C5 Bearing offers smooth rotation and low friction. Its chrome steel construction ensures durability in continuous operation, making it ideal for automated production lines.

Medical vs Industrial: Where 6305/C5 Bearing Excels
While 6305/C5 Bearing is versatile in industrial settings, it also fits medical devices like centrifuges, where precision and reliability are key. The metric sizing ensures compatibility with a wide range of equipment.
