Single Row Deep Groove Ball Bearings 6305/C3W64F

Single Row Deep Groove Ball Bearings 6305/C3W64F

The 6305/C3W64F is a single-row deep groove ball bearing with a 25mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 4631 lbf and operates smoothly at speeds up to 11000 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 232g, it’s a compact yet robust choice. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6305/C3W64F
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4631 lbf
  • Static Radial Load 254 lbf
  • Max Speed 11000 rpm
  • Weight 232 g
  • price（$） 9.009
Single Row Deep Groove Ball Bearings 6305/C3W64F dimension drawing
Download DWG Download PDF

Features

How Does 6305/C3W64F Bearing Reduce Friction?

6305/C3W64F Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
The chrome steel construction ensures durability while reducing friction during operation.

Solid oil lubrication in 6305/C3W64F Bearing maintains consistent performance, even at high speeds up to 11,000 rpm.
This design minimises wear, extending the bearing’s service life.

With a temperature range of -30°C to 120°C, 6305/C3W64F Bearing performs reliably in various conditions.
Its C3 radial clearance provides flexibility for thermal expansion in different applications.

The open seal design of 6305/C3W64F Bearing allows for easy inspection and maintenance.
Its standardised dimensions make it interchangeable with major brands like SKF.

Application

Common Applications of 6305/C3W64F Bearing
In industrial settings, 6305/C3W64F Bearing is widely used in electric motors and pumps due to its reliable radial load capacity. The solid oil lubrication ensures long service life even in continuous operation.

Automotive applications like alternators and wheel hubs benefit from 6305/C3W64F Bearing’s balanced performance. Its C3 clearance allows for thermal expansion, making it suitable for varying temperatures.

For household appliances such as washing machines, 6305/C3W64F Bearing provides quiet and smooth rotation. The chrome steel construction offers durability against daily wear and tear.

Where Is 6305/C3W64F Bearing Used?
You’ll often find 6305/C3W64F Bearing in conveyor systems, where its open design simplifies maintenance. The metric sizing ensures compatibility with standard industrial equipment.

In agricultural machinery, 6305/C3W64F Bearing handles radial loads in gearboxes and harvesters. Its solid oil lubrication works well in dusty or humid environments.

Optimized for Performance: 6305/C3W64F Bearing
6305/C3W64F Bearing is a go-to choice for small industrial fans, offering low friction and high-speed capability. The chrome steel balls enhance durability under constant use.

In power tools like drills, 6305/C3W64F Bearing ensures smooth operation with minimal vibration. Its ABEC 1 tolerance provides reliable precision for everyday tasks.

Automotive vs Industrial: Applications of 6305/C3W64F Bearing
In cars, 6305/C3W64F Bearing supports auxiliary components like water pumps, where its temperature range is ideal. The solid oil lubrication reduces the need for frequent maintenance.

For factory equipment, 6305/C3W64F Bearing excels in gear reducers and compressors. Its C3 clearance accommodates slight misalignments without compromising performance.
