Single Row Deep Groove Ball Bearings 6304TN

Single Row Deep Groove Ball Bearings 6304TN

The 6304TN is a single-row deep groove ball bearing with a 20mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 3574 lbf and spins smoothly at speeds up to 14,000 RPM.

Its open design allows for easy lubrication, while the nylon cage reduces friction and noise. The bearing operates reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or small machinery where radial loads are common.

Weighing just 144g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6304TN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3574 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 14000 rpm
  • Weight 144 g
  • price（$） 4.14
Single Row Deep Groove Ball Bearings 6304TN dimension drawing
Download DWG Download PDF

Features

Performance Features of 6304TN Bearing

6304TN Bearing is built with chrome steel rings and balls, offering strong radial load support up to 3574 lbf.
Its nylon cage ensures smooth operation and reduces friction, enhancing efficiency.
The open design allows for easy lubrication, making it suitable for various applications.
With a maximum speed of 14,000 rpm, it delivers reliable performance in demanding conditions.

Application

Key Fields for 6304TN Bearing
6304TN Bearing is widely used in industrial machinery, such as pumps and electric motors, where its deep groove design handles radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in demanding conditions.

In automotive applications, 6304TN Bearing fits well in components like alternators and water pumps, thanks to its reliable performance and ABEC 1 tolerance. Its metric sizing ensures compatibility with various vehicle models.

For home appliances, 6304TN Bearing works smoothly in devices like washing machines and fans, where quiet operation is essential. The nylon cage reduces friction, making it a durable choice for everyday use.

Automation systems benefit from 6304TN Bearing in robotic arms and conveyor belts, where precision and durability are key. Its chrome steel construction ensures stability even under continuous operation.
