Single Row Deep Groove Ball Bearings 6304/W64F

Single Row Deep Groove Ball Bearings 6304/W64F

The 6304/W64F is a single-row deep groove ball bearing with a 20mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 3574 lbf and spins smoothly at speeds up to 14,000 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage offers durability. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing just 144g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6304/W64F
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3574 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 14000 rpm
  • Weight 144 g
Single Row Deep Groove Ball Bearings 6304/W64F dimension drawing
Download DWG Download PDF

Features

Performance Features of 6304/W64F Bearing

6304/W64F Bearing is crafted with chrome steel rings and balls, offering strong radial load capacity up to 3574 lbf.
Its solid oil lubrication ensures smooth operation, reducing the need for frequent maintenance.

The open design allows for easy inspection and cleaning, making it suitable for various industrial applications.
With a maximum speed of 14,000 rpm, it delivers reliable performance in high-speed environments.

6304/W64F Bearing operates efficiently in temperatures ranging from -30°C to 120°C.
Its durable construction and precise tolerances ensure long-lasting performance under demanding conditions.

Application

Common Applications of 6304/W64F Bearing
In industrial settings, 6304/W64F Bearing is widely used in electric motors and pumps due to its reliable radial load capacity and solid oil lubrication. The open design ensures easy inspection and maintenance, ideal for continuous operation.

Where Is 6304/W64F Bearing Used?
You’ll often find 6304/W64F Bearing in automotive applications like alternators and water pumps, where its chrome steel construction handles high speeds smoothly. Its ABEC 1 tolerance makes it a cost-effective choice for standard precision needs.

Built for Heavy-Duty Use: 6304/W64F Bearing
This bearing excels in conveyor systems and agricultural machinery, thanks to its robust chrome steel cage and solid oil lubrication. The wide temperature range (-30° to 120°C) ensures performance in varying environments.

Light-Duty vs Heavy-Duty: Best Uses for 6304/W64F Bearing
For light-duty tasks like office printers, 6304/W64F Bearing offers quiet operation and longevity. In heavier applications like industrial fans, its dynamic load rating of 3574 lbf ensures durability under stress.

Perfect Fit for Automation: 6304/W64F Bearing
In robotic arms and automated assembly lines, 6304/W64F Bearing provides smooth rotation with minimal maintenance. The metric sizing (20mm×52mm×15mm) fits seamlessly into European and Asian machinery designs.
