Single Row Deep Groove Ball Bearings 6010-2RS1/C3WT

Single Row Deep Groove Ball Bearings 6010-2RS1/C3WT

The 6010-2RS1/C3WT is a single-row deep groove ball bearing with a 50mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4901 lbf and operates smoothly at speeds up to 8400 RPM.

Its sealed design keeps dirt out and grease in, reducing maintenance needs. The C3 radial clearance ensures reliable performance under varying temperatures, from -30°C to 120°C.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. It suits applications like electric motors or pumps where radial loads are common.

Weighing 261g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6010-2RS1/C3WT
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4901 lbf
  • Static Radial Load 3732 lbf
  • Max Speed 8400 rpm
  • Weight 261 g
Single Row Deep Groove Ball Bearings 6010-2RS1/C3WT dimension drawing
Download DWG Download PDF

Features

Why Choose 6010-2RS1/C3WT Bearing for Precision Tasks?

6010-2RS1/C3WT Bearing features a single-row deep groove design, ideal for handling radial loads with precision.

Its sealed construction protects against contaminants, ensuring smooth operation in various environments.

Made from chrome steel, it offers durability and resistance to wear, even under high dynamic loads of 4901 lbf.

With a maximum speed of 8,400 rpm, it balances performance and reliability for demanding applications.

Application

Industrial Uses of 6010-2RS1/C3WT Bearing
This bearing is commonly used in conveyor systems and electric motors, where its sealed design helps keep out dust and debris. The C3 clearance ensures reliable performance even with thermal expansion in industrial settings.

How Does 6010-2RS1/C3WT Bearing Improve Performance?
In automotive applications like alternators and water pumps, this bearing reduces friction for smoother operation. Its chrome steel construction provides good wear resistance under radial loads.

Perfect Fit for Automation: 6010-2RS1/C3WT Bearing
You’ll often find this bearing in robotic arms and packaging machines, where its consistent performance matters. The metric sizing makes it easy to replace in European-made equipment.

Medical vs Industrial: Where 6010-2RS1/C3WT Bearing Excels
While suitable for medical centrifuges, this bearing really shines in industrial fans and blowers. Its sealed design works well in environments where contamination must be prevented.

Light-Duty vs Heavy-Duty: Best Uses for 6010-2RS1/C3WT Bearing
For household appliances like washing machines, this bearing offers quiet operation. In heavier applications like small gearboxes, it maintains stability thanks to its robust construction.
