Single Row Deep Groove Ball Bearings 6009-ZR C3

Single Row Deep Groove Ball Bearings 6009-ZR C3

The 6009-ZR C3 is a single-row deep groove ball bearing with a 45mm bore and 75mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4721 lbf and operates smoothly at speeds reaching 9200 RPM.

Its shielded design keeps dirt out while maintaining easy access for lubrication. The chrome steel cage adds durability, making it suitable for continuous use.

This bearing fits well in temperatures from -30°C to 120°C, ideal for electric motors or pumps. It’s interchangeable with SKF models, offering a reliable replacement option.

Weighing 245g, it’s a compact yet robust choice for radial load applications. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6009-ZR C3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 75 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4721 lbf
  • Static Radial Load 3395 lbf
  • Max Speed 9200 rpm
  • Weight 245 g
Single Row Deep Groove Ball Bearings 6009-ZR C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6009-ZR C3 Bearing

6009-ZR C3 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 4721 lbf.

Its shielded design protects against contaminants, ensuring smooth operation in various environments.

The C3 radial clearance allows for thermal expansion, making it suitable for high-speed applications.

With a maximum speed of 9,200 rpm, it delivers reliable performance while maintaining efficiency.

Application

Key Fields for 6009-ZR C3 Bearing
The 6009-ZR C3 Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. Its C3 clearance allows for slight thermal expansion, making it suitable for variable temperature environments.

In automotive applications, 6009-ZR C3 Bearing fits well in wheel hubs and alternators, providing reliable radial load support. The chrome steel construction ensures durability even under continuous use.

For automation systems, 6009-ZR C3 Bearing works smoothly in conveyor belts and robotic arms. Its ABEC 1 tolerance balances precision and cost-effectiveness for general machinery needs.

Around the home, 6009-ZR C3 Bearing can be found in appliances like washing machines, where its quiet operation is a plus. The metric sizing makes it easy to replace in most European and Asian models.
