Single Row Deep Groove Ball Bearings 6300-2RSH

Single Row Deep Groove Ball Bearings 6300-2RSH

The 6300-2RSH is a compact single-row deep groove ball bearing with a 10mm bore and 35mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 1915 lbf and spins smoothly at speeds up to 15,000 RPM.

Its sealed design keeps grease in and dirt out, making it low-maintenance, while the stainless steel cage adds durability. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Perfect for small motors, pumps, or appliances where space is limited but performance matters.

Weighing just 0.054kg, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6300-2RSH
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.007mm to 0
  • Outer Dia 35 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 11 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 1915 lbf
  • Static Radial Load 764 lbf
  • Max Speed 15000 rpm
  • Weight 0.054 kg
  • price（$） 3.312
Single Row Deep Groove Ball Bearings 6300-2RSH dimension drawing
Download DWG Download PDF

Features

Why Choose 6300-2RSH Bearing for Precision Tasks?

6300-2RSH Bearing features a sealed design, protecting against dust and moisture for consistent performance.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

The grease lubrication reduces friction, allowing smooth operation at speeds up to 15,000 rpm.
With a dynamic radial load capacity of 1915 lbf, it handles demanding tasks reliably.

The stainless steel cage maintains ball alignment, extending the bearing’s service life.
Its compact size (10 mm×35 mm×11 mm) makes it suitable for space-constrained applications.

Application

Industrial Uses of 6300-2RSH Bearing
The 6300-2RSH Bearing is commonly used in industrial machinery like pumps and electric motors, where its sealed design helps keep contaminants out. Its chrome steel construction ensures durability even in demanding environments.

How Does 6300-2RSH Bearing Improve Performance?
In automotive applications, 6300-2RSH Bearing enhances efficiency in components like alternators and fans. The grease lubrication and sealed design reduce maintenance needs, making it a reliable choice for long-term use.

Perfect Fit for Automation: 6300-2RSH Bearing
For automated systems, 6300-2RSH Bearing works well in robotic arms and conveyor belts. Its high-speed capability and radial load handling make it suitable for precision tasks.

Medical vs Industrial: Where 6300-2RSH Bearing Excels
While 6300-2RSH Bearing is versatile in industrial settings, it also finds use in medical devices like small lab equipment. The stainless steel cage ensures smooth operation and resistance to wear.

Where to Use 6300-2RSH Bearing
In household appliances like washing machines, 6300-2RSH Bearing provides quiet and efficient performance. Its compact size and sealed design make it ideal for space-constrained applications.
