Single Row Deep Groove Ball Bearings 627-2RZTN9/C3GMG

Single Row Deep Groove Ball Bearings 627-2RZTN9/C3GMG

The 627-2RZTN9/C3GMG is a compact single row deep groove ball bearing, measuring 7mm in bore and 22mm in outer diameter. Made from chrome steel, it offers reliable performance for radial loads up to 629 lbf.

Its sealed design keeps dirt out and grease in, while the nylon cage ensures smooth operation at speeds up to 30,000 RPM. The bearing works in temperatures from -30°C to 120°C.

With C3 radial clearance, it’s suitable for applications where slight expansion is expected. Ideal for small motors, power tools, or appliances where space is limited.

Weighing just 12.7g, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it’s interchangeable with SKF bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 627-2RZTN9/C3GMG
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 7 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 22 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 629 lbf
  • Static Radial Load 248 lbf
  • Max Speed 30000 rpm
  • Weight 12.7 g
  • price（$） 3.33
Single Row Deep Groove Ball Bearings 627-2RZTN9/C3GMG dimension drawing
Download DWG Download PDF

Features

How Does 627-2RZTN9/C3GMG Bearing Reduce Friction?

627-2RZTN9/C3GMG Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
The chrome steel rings and balls minimise friction, ensuring efficient operation even at high speeds.
With a sealed construction, it prevents contaminants from entering, maintaining performance over time.
Its nylon cage further reduces friction and noise, making it suitable for quiet applications.

Application

Common Applications of 627-2RZTN9/C3GMG Bearing
In industrial settings, 627-2RZTN9/C3GMG Bearing is commonly used in small machinery like pumps and compressors, where its sealed design keeps contaminants out. The C3 clearance ensures smooth operation even under varying thermal conditions.

For automotive applications, 627-2RZTN9/C3GMG Bearing fits well in electric motors and alternators, thanks to its radial load capacity and high-speed capability. The nylon cage reduces noise, making it ideal for quieter vehicle systems.

In home appliances, 627-2RZTN9/C3GMG Bearing works efficiently in devices like washing machines and fans, where durability and low maintenance are key. Its compact size and metric dimensions make it easy to integrate into various designs.

Where Is 627-2RZTN9/C3GMG Bearing Used?
You’ll often find 627-2RZTN9/C3GMG Bearing in office equipment like printers and scanners, where its precision and reliability are essential. The sealed construction also helps prolong its lifespan in dusty environments.

In robotics, 627-2RZTN9/C3GMG Bearing supports small joints and actuators, providing smooth movement with minimal friction. The chrome steel rings ensure long-term performance even in repetitive motion scenarios.
