Single Row Deep Groove Ball Bearings 6210-2Z/VA216C

Single Row Deep Groove Ball Bearings 6210-2Z/VA216C

The 6210-2Z/VA216C is a single-row deep groove ball bearing with a 50mm bore and 90mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 7891 lbf and operates smoothly at speeds up to 7100 RPM.

Shielded on both sides, it keeps dirt out while maintaining smooth rotation. The chrome steel cage adds strength and longevity, making it a reliable choice for various applications.

Suitable for temperatures from -30°C to 120°C, this bearing works well in demanding environments. It’s interchangeable with SKF models, offering flexibility for replacements.

Ideal for electric motors, pumps, or industrial gearboxes where radial load support is needed. Compliant with RoHS and REACH standards, it’s a safe and practical option. Weighing 463g, it balances durability and ease of use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6210-2Z/VA216C
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 7891 lbf
  • Static Radial Load 5238 lbf
  • Max Speed 7100 rpm
  • Weight 463 g
Single Row Deep Groove Ball Bearings 6210-2Z/VA216C dimension drawing
Download DWG Download PDF

Features

How Does 6210-2Z/VA216C Bearing Reduce Friction?

6210-2Z/VA216C Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
Its chrome steel construction ensures durability while minimising friction during operation.

The shielded design protects against contaminants, maintaining performance in various environments.
With a dynamic radial load capacity of 7891 lbf, it handles demanding applications with ease.

6210-2Z/VA216C Bearing operates efficiently at speeds up to 7,100 rpm, balancing speed and reliability.
Its temperature range of -30°C to 120°C makes it suitable for diverse working conditions.

Application

Industrial Uses of 6210-2Z/VA216C Bearing
6210-2Z/VA216C Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability even in demanding environments.

In automotive applications, 6210-2Z/VA216C Bearing works well in wheel hubs and alternators, providing reliable radial load support. Its ABEC 1 tolerance makes it suitable for standard precision requirements.

For automation systems, 6210-2Z/VA216C Bearing fits nicely in conveyor rollers and robotic joints. The shielded seals offer added protection against dust, extending the bearing’s service life.

In household appliances, 6210-2Z/VA216C Bearing can be found in washing machines and fans. Its balanced performance and moderate speed capability make it a practical choice for everyday use.
