Single Row Deep Groove Ball Bearings 6217-2Z/C3WT

Single Row Deep Groove Ball Bearings 6217-2Z/C3WT

The 6217-2Z/C3WT is a single-row deep groove ball bearing with an 85mm bore and 150mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 18884 lbf and operates smoothly at speeds up to 4300 RPM.

Shielded on both sides, it keeps contaminants out while maintaining smooth rotation. The C3 radial clearance allows for slight thermal expansion, making it reliable in varying temperatures from -30°C to 120°C.

This bearing is interchangeable with SKF models, offering a cost-effective alternative for replacements. Its robust design suits applications like electric motors or pumps where radial loads are common.

Weighing 1740g, it’s a durable choice for industrial use. Compliant with RoHS and REACH standards, it meets safety and environmental requirements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6217-2Z/C3WT
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 28 mm
  • Width Tolerance -0.200mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 18884 lbf
  • Static Radial Load 13916 lbf
  • Max Speed 4300 rpm
  • Weight 1740 g
Single Row Deep Groove Ball Bearings 6217-2Z/C3WT dimension drawing
Download DWG Download PDF

Features

Performance Features of 6217-2Z/C3WT Bearing

6217-2Z/C3WT Bearing is built for radial loads, with a dynamic radial load capacity of 18,884 lbf.
Its chrome steel construction ensures durability and resistance to wear in various applications.

The shielded design protects 6217-2Z/C3WT Bearing from contaminants, extending its service life.
It operates smoothly within a temperature range of -30°C to 120°C, suitable for diverse environments.

With a maximum speed of 4,300 rpm, 6217-2Z/C3WT Bearing balances performance and reliability.
The C3 radial clearance allows for thermal expansion, ensuring consistent operation under load.

Application

Industrial Uses of 6217-2Z/C3WT Bearing
6217-2Z/C3WT Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The C3 radial clearance ensures reliable performance even under varying thermal conditions.

Where Is 6217-2Z/C3WT Bearing Used?
In automotive applications, 6217-2Z/C3WT Bearing fits well in wheel hubs and alternators, thanks to its robust chrome steel construction. Its metric sizing makes it a versatile choice for various vehicle models.

Perfect Fit for Automation: 6217-2Z/C3WT Bearing
For automated systems, 6217-2Z/C3WT Bearing works smoothly in conveyor belts and robotic arms, handling radial loads with ease. The shielded seals reduce maintenance needs, ideal for high-use environments.

Medical vs Industrial: Where 6217-2Z/C3WT Bearing Excels
In medical devices, 6217-2Z/C3WT Bearing offers quiet operation for equipment like centrifuges. Its industrial strength also makes it suitable for heavy machinery, balancing durability and precision.
