Single Row Deep Groove Ball Bearings 6213/W64

Single Row Deep Groove Ball Bearings 6213/W64

The 6213/W64 is a single-row deep groove ball bearing with a 65mm bore and 120mm outer diameter, crafted from sturdy chrome steel for reliable performance. It handles radial loads up to 12859 lbf and operates smoothly at speeds up to 5300 RPM.

Its solid oil lubrication reduces maintenance needs, while the chrome steel cage ensures durability. The bearing works efficiently in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like electric motors or pumps where radial load support is key.

Weighing 979g, it balances strength and manageability. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6213/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 12859 lbf
  • Static Radial Load 9015 lbf
  • Max Speed 5300 rpm
  • Weight 979 g
Single Row Deep Groove Ball Bearings 6213/W64 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6213/W64 Bearing

6213/W64 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 12859 lbf.

Its solid oil lubrication ensures smooth operation, reducing the need for frequent maintenance.

The bearing operates efficiently within a temperature range of -30° to 120°C, suitable for various environments.

With a maximum speed of 5,300 rpm, it balances performance and durability in demanding applications.

Application

Industrial Uses of 6213/W64 Bearing
The 6213/W64 Bearing is commonly used in industrial machinery like pumps and electric motors, where its solid oil lubrication ensures long service life. Its open design allows for easy inspection and maintenance in demanding environments.

Where Is 6213/W64 Bearing Used?
You’ll often find 6213/W64 Bearing in automotive applications such as alternators and transmission systems, thanks to its reliable radial load handling. The chrome steel construction also makes it resistant to wear under high-speed conditions.

Built for Heavy-Duty Use: 6213/W64 Bearing
In automation systems, 6213/W64 Bearing supports robotic arms and conveyor belts, where its ABEC 1 precision ensures smooth operation. The wide temperature range makes it suitable for both hot and cold working environments.

Medical vs Industrial: Where 6213/W64 Bearing Excels
While 6213/W64 Bearing performs well in industrial gearboxes, it’s also found in medical devices like centrifuges, where its low vibration is crucial. The solid oil lubrication reduces the need for frequent re-greasing, ideal for high-use scenarios.

Perfect Fit for Automation: 6213/W64 Bearing
For household appliances like washing machines, 6213/W64 Bearing offers quiet and efficient performance. Its metric sizing ensures compatibility with a variety of European and Asian appliance models.
