Single Row Deep Groove Ball Bearings 6212/W64

Single Row Deep Groove Ball Bearings 6212/W64

The 6212/W64 is a single-row deep groove ball bearing with a 60mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 1178 lbf and operates smoothly at speeds up to 5600 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 762g, it balances strength and practicality. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6212/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 22 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1178 lbf
  • Static Radial Load 8138 lbf
  • Max Speed 5600 rpm
  • Weight 762 g
  • price（$） 40.446
Single Row Deep Groove Ball Bearings 6212/W64 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6212/W64 Bearing

6212/W64 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 1178 lbf, ensuring steady performance in various applications.

The solid oil lubrication reduces friction, extending maintenance intervals.
With a maximum speed of 5,600 rpm, it balances efficiency and durability.

6212/W64 Bearing operates smoothly in temperatures from -30°C to 120°C.
Its open design allows for easy inspection and maintenance.

Application

Common Applications of 6212/W64 Bearing
The 6212/W64 Bearing is widely used in industrial machinery, such as pumps and electric motors, where its radial load capacity ensures reliable performance. Its solid oil lubrication reduces maintenance needs, making it suitable for continuous operation.

In automotive applications, 6212/W64 Bearing fits well in wheel hubs and alternators, providing smooth rotation under varying loads. The chrome steel construction offers durability, even in demanding driving conditions.

For household appliances like washing machines, 6212/W64 Bearing’s quiet operation and long lifespan make it a dependable choice. The open design allows for easy inspection and cleaning, extending its service life.

Where Is 6212/W64 Bearing Used?
You’ll often find 6212/W64 Bearing in conveyor systems, where its radial load handling keeps things running smoothly. The ABEC 1 tolerance ensures consistent performance without unnecessary complexity.

In agricultural equipment, 6212/W64 Bearing handles dusty environments well, thanks to its solid oil lubrication. The metric sizing makes it easy to replace in older machinery.

Built for Versatility: 6212/W64 Bearing
The 6212/W64 Bearing works well in both light and medium-duty applications, from office printers to small industrial fans. Its temperature range allows it to perform reliably in various climates.

For DIY projects, 6212/W64 Bearing’s compatibility with common SKF models makes it a handy spare part. The chrome steel cage adds extra resilience against wear over time.

Automotive vs Industrial: Applications of 6212/W64 Bearing
In cars, 6212/W64 Bearing often supports auxiliary components like idler pulleys, where its radial load capacity is key. The solid oil lubrication ensures longevity even in high-mileage vehicles.

Factory settings benefit from 6212/W64 Bearing in gearboxes and small conveyors, where its straightforward design simplifies maintenance. The ISO P0 tolerance is sufficient for most general-purpose uses.
