Single Row Deep Groove Ball Bearings 6210-2Z/GJN

Single Row Deep Groove Ball Bearings 6210-2Z/GJN

The 6210-2Z/GJN is a single row deep groove ball bearing with a 50mm bore and 90mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 7891 lbf and operates smoothly at speeds up to 7100 RPM.

Its shielded design keeps dirt out while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 463g, it’s a robust yet lightweight option. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6210-2Z/GJN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 7891 lbf
  • Static Radial Load 5238 lbf
  • Max Speed 7100 rpm
  • Weight 463 g
  • price（$） 9.135
Single Row Deep Groove Ball Bearings 6210-2Z/GJN dimension drawing
Download DWG Download PDF

Features

Performance Features of 6210-2Z/GJN Bearing

6210-2Z/GJN Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 7891 lbf.
Its shielded design protects against dust and debris, ensuring smooth operation in various environments.

The ABEC 1 tolerance class ensures reliable performance, while the chrome steel cage enhances durability.
With a maximum speed of 7,100 rpm, it balances efficiency and longevity.

6210-2Z/GJN Bearing operates in temperatures from -30°C to 120°C, making it versatile for different applications.
Its compact size (50 mm×90 mm×20 mm) allows for easy integration into various machinery.

Application

Common Applications of 6210-2Z/GJN Bearing
The 6210-2Z/GJN Bearing is widely used in industrial machinery, such as electric motors and pumps, where its shielded design helps keep contaminants out. Its chrome steel construction ensures durability in demanding environments.

In automotive applications, 6210-2Z/GJN Bearing is often found in wheel hubs and alternators, providing reliable radial load support. The metric sizing makes it a versatile choice for various vehicle models.

For household appliances like washing machines, 6210-2Z/GJN Bearing offers smooth and quiet operation. Its shielded seals help extend the bearing’s lifespan by reducing dust and moisture ingress.

Where Is 6210-2Z/GJN Bearing Used?
You’ll often spot 6210-2Z/GJN Bearing in conveyor systems, where its radial load capacity and shielded design are ideal for continuous operation. The chrome steel cage adds extra strength for heavy-duty use.

In agricultural equipment, 6210-2Z/GJN Bearing handles the tough conditions of tractors and harvesters. Its wide temperature range ensures performance even in extreme weather.

Built for Versatility: 6210-2Z/GJN Bearing
The 6210-2Z/GJN Bearing is a go-to for small industrial fans, balancing efficiency and durability. Its ABEC 1 tolerance ensures reliable performance without over-engineering.

In workshop tools like grinders, 6210-2Z/GJN Bearing provides steady rotation under moderate loads. The shielded design keeps debris out, reducing maintenance needs.

Automotive vs Industrial: Applications of 6210-2Z/GJN Bearing
In cars, 6210-2Z/GJN Bearing supports auxiliary components like idler pulleys, ensuring smooth belt operation. Its static load rating makes it dependable for long-term use.

For factory equipment, 6210-2Z/GJN Bearing fits well in gearboxes and reducers. The metric dimensions simplify replacements in European and Asian machinery.
