Single Row Deep Groove Ball Bearings 6207-2Z/C3HT

Single Row Deep Groove Ball Bearings 6207-2Z/C3HT

The 6207-2Z/C3HT is a single-row deep groove ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 5778 lbf and spins smoothly at speeds up to 9200 RPM.

Its shielded design keeps dirt out while maintaining easy access for lubrication. The C3 radial clearance ensures reliable performance under varying temperatures, from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for use in electric motors, pumps, or industrial gearboxes where radial loads are common.

Weighing just 288g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6207-2Z/C3HT
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 5778 lbf
  • Static Radial Load 3462 lbf
  • Max Speed 9200 rpm
  • Weight 288 g
Single Row Deep Groove Ball Bearings 6207-2Z/C3HT dimension drawing
Download DWG Download PDF

Features

Performance Features of 6207-2Z/C3HT Bearing

6207-2Z/C3HT Bearing is designed for radial loads, with a dynamic radial load capacity of 5778 lbf.
Its shielded design helps keep contaminants out, ensuring smoother operation.

The chrome steel construction of 6207-2Z/C3HT Bearing provides durability and resistance to wear.
It operates efficiently at speeds up to 9,200 rpm, making it suitable for various applications.

6207-2Z/C3HT Bearing can handle temperatures from -30°C to 120°C, adapting to different working conditions.
Its C3 radial clearance ensures reliable performance even under varying thermal conditions.

With a compact size of 35 mm×72 mm×17 mm, 6207-2Z/C3HT Bearing fits easily into tight spaces.
The balanced design reduces vibration, contributing to quieter operation.

Application

Industrial Uses of 6207-2Z/C3HT Bearing
6207-2Z/C3HT Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The C3 clearance ensures reliable performance even under varying thermal conditions.

In automotive applications, 6207-2Z/C3HT Bearing fits well in alternators and wheel hubs, offering smooth radial load support. Its chrome steel construction provides durability for long-term use in demanding environments.

For automation systems, 6207-2Z/C3HT Bearing works efficiently in robotic arms and conveyor belts, thanks to its balanced load capacity. The metric sizing makes it easy to integrate into various European and Asian equipment designs.

Where to Use 6207-2Z/C3HT Bearing
You’ll find 6207-2Z/C3HT Bearing in household appliances like washing machines, where its shielded design protects against dust and moisture. The wide temperature range also makes it suitable for different climates.

In small machinery such as power tools, 6207-2Z/C3HT Bearing delivers consistent performance under high-speed rotations. Its lightweight design ensures minimal energy loss, improving overall efficiency.
