Single Row Deep Groove Ball Bearings 6206/VW514

Single Row Deep Groove Ball Bearings 6206/VW514

The 6206/VW514 is a single-row deep groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel for lasting performance. It handles radial loads up to 4384 lbf and spins smoothly at speeds up to 11000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability under stress. The bearing operates reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing just 199g, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards, it’s a safe and reliable option for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6206/VW514
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4384 lbf
  • Static Radial Load 254 lbf
  • Max Speed 11000 rpm
  • Weight 199 g
Single Row Deep Groove Ball Bearings 6206/VW514 dimension drawing
Download DWG Download PDF

Features

How Does 6206/VW514 Bearing Reduce Friction?

6206/VW514 Bearing features a single-row deep groove design, optimised for smooth radial load handling.
Its chrome steel construction ensures durability while reducing friction during operation.
The open seal type allows for easy maintenance and efficient lubrication.
With a maximum speed of 11,000 rpm, it delivers reliable performance in various applications.

Application

Industrial Uses of 6206/VW514 Bearing
6206/VW514 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, extending service life in demanding environments.

Where Is 6206/VW514 Bearing Used?
In automotive applications, 6206/VW514 Bearing fits well in alternators and wheel hubs, providing reliable performance under continuous radial loads. Its metric sizing makes it a versatile choice for various vehicle models.

Perfect Fit for Automation: 6206/VW514 Bearing
For robotic arms and conveyor systems, 6206/VW514 Bearing offers precise movement thanks to its deep groove design. The chrome steel construction ensures durability in high-speed operations.

Medical vs Industrial: Where 6206/VW514 Bearing Excels
In medical devices like centrifuges, 6206/VW514 Bearing delivers quiet and efficient performance. Its ISO P0 tolerance makes it suitable for precision instruments requiring consistent accuracy.

Light-Duty vs Heavy-Duty: Best Uses for 6206/VW514 Bearing
From household appliances like washing machines to industrial gearboxes, 6206/VW514 Bearing handles both light and moderate loads with ease. The wide temperature range adds to its adaptability in different environments.
