Single Row Deep Groove Ball Bearings 6206-2Z/GJNVQ086

Single Row Deep Groove Ball Bearings 6206-2Z/GJNVQ086

The 6206-2Z is a single-row deep groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 4384 lbf and spins smoothly at speeds up to 11000 RPM.

Its shielded design keeps dirt out while maintaining smooth operation, and the chrome steel cage adds durability. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or small machinery where radial loads are common.

Weighing just 199g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6206-2Z/GJNVQ086
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4384 lbf
  • Static Radial Load 254 lbf
  • Max Speed 11000 rpm
  • Weight 199 g
Single Row Deep Groove Ball Bearings 6206-2Z/GJNVQ086 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6206-2Z/GJNVQ086 Bearing

6206-2Z/GJNVQ086 Bearing is built with chrome steel rings and balls, offering strong radial load capacity.
Its dynamic radial load reaches 4384 lbf, making it suitable for various industrial applications.

The shielded design protects against contaminants, ensuring smooth operation in dusty environments.
With a maximum speed of 11,000 rpm, it delivers reliable performance under high-speed conditions.

6206-2Z/GJNVQ086 Bearing operates efficiently within a temperature range of -30°C to 120°C.
Its chrome steel cage enhances durability, reducing maintenance needs over time.

Application

Common Applications of 6206-2Z/GJNVQ086 Bearing
6206-2Z/GJNVQ086 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in demanding environments.

In automotive applications, 6206-2Z/GJNVQ086 Bearing supports components like alternators and wheel hubs, providing smooth rotation under radial loads. Its metric sizing makes it a versatile choice for various vehicle models.

For home appliances, 6206-2Z/GJNVQ086 Bearing is often found in washing machines and fans, where reliability and low maintenance are key. The shielded seals help extend its lifespan in everyday use.

In automation systems, 6206-2Z/GJNVQ086 Bearing is used in conveyor belts and robotic arms, offering consistent performance. Its ABEC 1 tolerance ensures reliable operation in precision applications.
