Single Row Deep Groove Ball Bearings 6205/HN3C3

Single Row Deep Groove Ball Bearings 6205/HN3C3

The 6205/HN3C3 is a single-row deep groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 3147 lbf and can spin at speeds up to 13,000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing operates smoothly in temperatures ranging from -30°C to 120°C.

With a C3 radial clearance, it offers flexibility in various applications. This model is interchangeable with SKF bearings, making it a practical choice for replacements.

Ideal for machinery like electric motors or pumps where radial loads are common. Weighing just 128g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205/HN3C3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 13000 rpm
  • Weight 128 g
Single Row Deep Groove Ball Bearings 6205/HN3C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6205/HN3C3 Bearing

6205/HN3C3 Bearing is crafted with chrome steel rings and balls, offering strong radial load support.
Its dynamic radial load capacity reaches 3147 lbf, making it suitable for various applications.

The open design of 6205/HN3C3 Bearing allows for easy lubrication and maintenance.
With a maximum speed of 13,000 rpm, it ensures smooth and efficient operation.

6205/HN3C3 Bearing operates in temperatures from -30°C to 120°C, adapting to diverse environments.
Its C3 radial clearance provides flexibility in different operating conditions.

The chrome steel cage in 6205/HN3C3 Bearing enhances durability and reduces wear.
This design ensures long service life and reliable performance.

Application

Common Applications of 6205/HN3C3 Bearing
In industrial settings, 6205/HN3C3 Bearing is commonly used in electric motors and pumps, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending its service life in demanding conditions.

Where Is 6205/HN3C3 Bearing Used?
You’ll often find 6205/HN3C3 Bearing in automotive applications like alternators and wheel hubs, thanks to its balanced radial load handling. Its chrome steel construction makes it durable enough for high-speed rotations.

Ideal for Precision: 6205/HN3C3 Bearing
For medical devices such as centrifuges, 6205/HN3C3 Bearing offers smooth operation due to its C3 clearance. The consistent performance makes it a trusted choice in sensitive equipment.

Automotive vs Industrial: Applications of 6205/HN3C3 Bearing
In cars, 6205/HN3C3 Bearing handles radial loads in transmissions, while in factories, it supports conveyor belts. Its versatility and durability make it suitable for both environments.

Perfect Fit for Automation: 6205/HN3C3 Bearing
In robotic arms and automated systems, 6205/HN3C3 Bearing provides reliable radial support. The metric sizing ensures compatibility with various machinery components.
