Single Row Deep Groove Ball Bearings 6205/C5

Single Row Deep Groove Ball Bearings 6205/C5

The 6205/C5 is a single-row deep groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel for reliable performance. It handles radial loads up to 3147 lbf and can spin at speeds up to 13,000 RPM, making it suitable for high-speed applications.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability under heavy use. The bearing operates smoothly in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Ideal for use in electric motors, pumps, or gearboxes where radial loads are common.

Weighing just 128g, it’s lightweight yet robust, and complies with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205/C5
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C5
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 13000 rpm
  • Weight 128 g
  • price（$） 3.492
Single Row Deep Groove Ball Bearings 6205/C5 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6205/C5 Bearing

6205/C5 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 3147 lbf, ensuring reliable performance in various applications.
The chrome steel cage maintains ball alignment, reducing friction and extending operational life.
With a maximum speed of 13,000 rpm, it combines durability with high-speed efficiency.

How Does 6205/C5 Bearing Reduce Friction?

6205/C5 Bearing features a deep groove design that minimises friction during operation.
The chrome steel construction ensures smooth movement, even under significant radial loads.
Its open seal type allows for easy lubrication, further enhancing performance.
This design makes it suitable for applications requiring both speed and reliability.

Engineered for Precision: 6205/C5 Bearing

6205/C5 Bearing meets ABEC 1 and ISO P0 tolerance standards, ensuring precise performance.
The C5 radial clearance provides optimal operation under varying temperature conditions.
Its compact size (25 mm×52 mm×15 mm) makes it ideal for space-constrained applications.
The bearing operates efficiently within a temperature range of -30°C to 120°C.

Why Choose 6205/C5 Bearing for Radial Loads?

6205/C5 Bearing is designed to handle radial loads up to 3147 lbf with ease.
The single-row deep groove construction ensures even load distribution.
Its chrome steel components resist wear, maintaining performance over time.
This bearing is a cost-effective solution, priced at ￡3.88, without compromising quality.

Built for Reliability: 6205/C5 Bearing

6205/C5 Bearing’s chrome steel construction ensures long-lasting durability.
The open design allows for straightforward maintenance and inspection.
Weighing just 128 g, it offers a lightweight yet robust solution.
Compliant with RoHS and REACH standards, it meets environmental and safety requirements.

Application

Industrial Uses of 6205/C5 Bearing
6205/C5 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, making it suitable for high-speed applications.

In automotive systems, 6205/C5 Bearing fits well in components such as alternators and wheel hubs, providing smooth rotation under varying loads. Its metric sizing ensures compatibility with a wide range of vehicle models.

For automation equipment, 6205/C5 Bearing’s chrome steel construction offers durability in robotic arms and conveyor systems. The C5 clearance provides optimal performance in environments with temperature fluctuations.

Where Is 6205/C5 Bearing Used?
You’ll find 6205/C5 Bearing in household appliances like washing machines, where its quiet operation and longevity are key. The chrome steel cage enhances its resistance to wear in daily use.

In medical devices, 6205/C5 Bearing supports precise movements in equipment like lab centrifuges. Its temperature range makes it reliable in both sterile and high-use environments.
