Single Row Deep Groove Ball Bearings 6205-2RSH/C3HMTF7

Single Row Deep Groove Ball Bearings 6205-2RSH/C3HMTF7

The 6205-2RSH/C3HMTF7 is a single-row deep groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 3147 lbf and spins smoothly at speeds up to 13,000 RPM.

Sealed on both sides, it keeps dirt out and grease in, making it low-maintenance. The C3 radial clearance allows for slight thermal expansion, ideal for fluctuating temperatures.

This bearing suits a range of applications, from electric motors to conveyor systems, where reliability is key. It’s interchangeable with SKF models, offering a cost-effective alternative.

Weighing just 128g, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it operates in temperatures from -30°C to 120°C.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205-2RSH/C3HMTF7
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 13000 rpm
  • Weight 128 g
Single Row Deep Groove Ball Bearings 6205-2RSH/C3HMTF7 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6205-2RSH/C3HMTF7 Bearing

6205-2RSH/C3HMTF7 Bearing is designed for radial loads, with a dynamic radial load capacity of 3147 lbf.
Its sealed construction helps keep contaminants out, ensuring smoother operation.

The chrome steel rings and balls provide durability, while the C3 radial clearance allows for thermal expansion.
This makes it suitable for applications with varying temperatures.

With a maximum speed of 13,000 rpm, it balances performance and longevity.
The sealed design also reduces maintenance needs, making it a practical choice.

Its compact size (25 mm × 52 mm × 15 mm) fits well in various machinery.
The bearing operates efficiently within a temperature range of -30°C to 120°C.

Application

Where Is 6205-2RSH/C3HMTF7 Bearing Used?
6205-2RSH/C3HMTF7 Bearing is commonly used in industrial machinery like pumps and electric motors, where its sealed design keeps contaminants out. The C3 clearance ensures reliable performance under varying temperatures and loads.

In automotive applications, 6205-2RSH/C3HMTF7 Bearing fits well in wheel hubs and alternators, providing smooth rotation. Its chrome steel construction offers durability for long-term use in demanding conditions.

For home appliances, 6205-2RSH/C3HMTF7 Bearing works efficiently in washing machines and fans. The sealed design reduces maintenance needs, making it a hassle-free choice for everyday devices.

In automation systems, 6205-2RSH/C3HMTF7 Bearing supports robotic arms and conveyor belts. Its high-speed capability and radial load handling make it versatile for precision tasks.
