Single Row Deep Groove Ball Bearings 6205/22

Single Row Deep Groove Ball Bearings 6205/22

The 6205/22 is a single-row deep groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel for durability. It handles radial loads up to 3147 lbf and operates smoothly at speeds up to 13,000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures reliable performance under stress. The bearing functions well in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s ideal for applications like electric motors or small machinery where radial loads are common.

Weighing just 128g, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205/22
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 13000 rpm
  • Weight 128 g
Single Row Deep Groove Ball Bearings 6205/22 dimension drawing
Download DWG Download PDF

Features

How Does 6205/22 Bearing Reduce Friction?

6205/22 Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
Its chrome steel construction ensures durability while minimising friction during operation.

The open seal type allows for easy maintenance and efficient heat dissipation.
With a maximum speed of 13,000 rpm, it delivers reliable performance in various applications.

6205/22 Bearing operates within a wide temperature range of -30°C to 120°C, suitable for diverse environments.
Its dynamic radial load capacity of 3147 lbf ensures long-lasting performance under pressure.

Application

Industrial Uses of 6205/22 Bearing
The 6205/22 Bearing is commonly used in conveyor systems and electric motors, where its radial load capacity ensures smooth operation. Its open design allows for easy lubrication, making it suitable for dusty environments.

Key Fields for 6205/22 Bearing
In automotive applications, 6205/22 Bearing fits well in alternators and water pumps due to its balanced performance. The chrome steel construction provides durability under continuous use.

Where Is 6205/22 Bearing Used?
You’ll find 6205/22 Bearing in household appliances like washing machines, where its quiet operation is a plus. The metric sizing makes it compatible with various European and Asian models.

Built for Heavy-Duty Use: 6205/22 Bearing
For industrial fans and small machinery, 6205/22 Bearing offers reliable performance with minimal maintenance. Its ABEC 1 tolerance ensures consistent operation in moderate precision applications.

Automotive vs Industrial: Applications of 6205/22 Bearing
In cars, 6205/22 Bearing handles radial loads in gearboxes, while in factories, it supports machinery like small presses. Its versatility makes it a go-to choice for many engineers.
