Single Row Deep Groove Ball Bearings 6200-RS1/MT

Single Row Deep Groove Ball Bearings 6200-RS1/MT

The 6200-RS1/MT is a compact single-row deep groove ball bearing with a 10mm bore and 30mm outer diameter, crafted from sturdy chrome steel. Its sealed design keeps dirt out and lubrication in, making it low-maintenance.

This model handles radial loads up to 1147 lbf and spins smoothly at speeds up to 24,000 RPM. The chrome steel cage ensures durability, even in demanding conditions.

With a temperature range of -30°C to 120°C, it’s versatile for various environments. The bearing is interchangeable with SKF models, offering a reliable replacement option.

Weighing just 32g, it’s lightweight yet robust. Ideal for small motors, pumps, or appliances where space is limited but performance matters. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6200-RS1/MT
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 30 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 9 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1147 lbf
  • Static Radial Load 54 lbf
  • Max Speed 24000 rpm
  • Weight 32 g
Single Row Deep Groove Ball Bearings 6200-RS1/MT dimension drawing
Download DWG Download PDF

Features

How Does 6200-RS1/MT Bearing Reduce Friction?

6200-RS1/MT Bearing features a sealed design, preventing contaminants from entering and reducing friction.
Its chrome steel construction ensures smooth operation, even at high speeds up to 24,000 rpm.
The single-row deep groove design enhances radial load capacity, supporting up to 1147 lbf.
With a temperature range of -30°C to 120°C, it performs reliably in various conditions.

Application

Common Applications of 6200-RS1/MT Bearing
The 6200-RS1/MT Bearing is widely used in small electric motors, thanks to its sealed design which keeps out dust and moisture. Its compact size makes it ideal for tight spaces in household appliances like washing machines.

Industrial Uses of 6200-RS1/MT Bearing
In conveyor systems, the 6200-RS1/MT Bearing handles radial loads efficiently, ensuring smooth operation. The chrome steel construction provides durability in demanding industrial environments.

What Makes 6200-RS1/MT Bearing a Preferred Choice?
With its ABEC 1 tolerance, the 6200-RS1/MT Bearing offers reliable performance in office equipment like printers. The sealed design also reduces maintenance needs, making it a cost-effective solution.

Perfect Fit for Automation: 6200-RS1/MT Bearing
The 6200-RS1/MT Bearing works well in robotic arms, where precision and low friction are key. Its temperature range allows it to perform consistently in various operating conditions.

Light-Duty vs Heavy-Duty: Best Uses for 6200-RS1/MT Bearing
For light-duty applications like fans, the 6200-RS1/MT Bearing provides quiet and efficient operation. In heavier tasks, its dynamic load capacity ensures long-lasting performance.
