Single Row Deep Groove Ball Bearings 61805-2RS1/C3

Single Row Deep Groove Ball Bearings 61805-2RS1/C3

The 61805-2RS1/C3 is a compact single row deep groove ball bearing, measuring 25mm by 37mm by 7mm. Made from chrome steel, it handles radial loads up to 980 lbf and spins smoothly at speeds up to 24,000 RPM.

Its sealed design keeps dirt out and grease in, making it low-maintenance. The C3 radial clearance allows for slight thermal expansion, ideal for varying temperatures.

This bearing works well in temperatures from -30°C to 120°C. It’s a reliable choice for small electric motors or appliances where space is tight.

Weighing just 0.021kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it’s interchangeable with SKF bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 61805-2RS1/C3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 37 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 980 lbf
  • Static Radial Load 585 lbf
  • Max Speed 24000 rpm
  • Weight 0.021 kg
  • price（$） 16.659
Single Row Deep Groove Ball Bearings 61805-2RS1/C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 61805-2RS1/C3 Bearing

61805-2RS1/C3 Bearing is designed with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 980 lbf, ensuring reliable performance in various applications.

The sealed design of 61805-2RS1/C3 Bearing protects against dust and moisture, enhancing durability.
With a maximum speed of 24,000 rpm, it provides smooth and efficient operation.

61805-2RS1/C3 Bearing operates in temperatures from -30°C to 120°C, making it versatile for different environments.
Its compact size of 25 mm×37 mm×7 mm allows for easy integration into various machinery.

The C3 radial clearance ensures optimal performance under varying load conditions.
This bearing is interchangeable with SKF models, offering flexibility in replacements.

Application

Common Applications of 61805-2RS1/C3 Bearing
In industrial settings, 61805-2RS1/C3 Bearing is widely used in small electric motors and pumps due to its compact size and reliable radial load capacity. The sealed design helps keep contaminants out, extending service life in dusty environments.

How Does 61805-2RS1/C3 Bearing Improve Performance?
For automotive applications like alternators and cooling fans, 61805-2RS1/C3 Bearing offers smooth rotation and low noise. Its C3 clearance provides better heat dissipation, ideal for high-speed operations.

Built for Heavy-Duty Use: 61805-2RS1/C3 Bearing
In household appliances such as washing machines, 61805-2RS1/C3 Bearing handles frequent start-stop cycles with ease. The chrome steel construction ensures durability even under constant vibration.

Medical vs Industrial: Where 61805-2RS1/C3 Bearing Excels
While suitable for medical devices like dental handpieces, 61805-2RS1/C3 Bearing truly shines in industrial gearboxes. Its ABEC 1 tolerance balances precision and cost-effectiveness for general machinery.

Perfect Fit for Automation: 61805-2RS1/C3 Bearing
In robotics and conveyor systems, 61805-2RS1/C3 Bearing’s low-profile design saves space without sacrificing performance. The sealed rings prevent lubricant leakage in cleanroom environments.
