Single Row Deep Groove Ball Bearings 609-2Z/C3GJN

Single Row Deep Groove Ball Bearings 609-2Z/C3GJN

The 609-2Z/C3GJN is a compact single row deep groove ball bearing, measuring 9mm by 24mm by 7mm. Made from durable chrome steel, it handles radial loads up to 642 lbf and spins smoothly at speeds up to 32,000 RPM.

Its shielded design keeps dust out while the C3 radial clearance allows for slight misalignment. The bearing operates in temperatures from -30°C to 120°C, making it versatile for various conditions.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for small motors, fans, or appliances where space is limited but performance is key.

Weighing just 14.7g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 609-2Z/C3GJN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 9 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 24 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 642 lbf
  • Static Radial Load 260 lbf
  • Max Speed 32000 rpm
  • Weight 14.7 g
Single Row Deep Groove Ball Bearings 609-2Z/C3GJN dimension drawing
Download DWG Download PDF

Features

Performance Features of 609-2Z/C3GJN Bearing

609-2Z/C3GJN Bearing is built with chrome steel rings and balls, offering reliable radial load support.
Its dynamic radial load capacity of 642 lbf ensures steady performance in various applications.

The shielded design protects against contaminants, making it suitable for dusty environments.
With a maximum speed of 32,000 rpm, it delivers smooth operation in high-speed settings.

609-2Z/C3GJN Bearing’s C3 radial clearance allows for thermal expansion, enhancing durability.
Its compact size (9 mm×24 mm×7 mm) makes it ideal for space-constrained installations.

Application

Common Applications of 609-2Z/C3GJN Bearing
609-2Z/C3GJN Bearing works well in small electric motors, like those in household appliances or power tools, thanks to its compact size and shielded design. The chrome steel construction ensures it handles everyday wear without fuss.

In conveyor systems, 609-2Z/C3GJN Bearing keeps things running smoothly with its radial load capacity and C3 clearance for slight misalignments. It’s a no-nonsense choice for light industrial settings.

You’ll also spot 609-2Z/C3GJN Bearing in office printers, where its low noise and steady performance matter. The metric sizing fits neatly into most European and Asian-made devices.
