Single Row Deep Groove Ball Bearings 609-2Z/C2EGWGVQ514

Single Row Deep Groove Ball Bearings 609-2Z/C2EGWGVQ514

The 609-2Z/C2EGWGVQ514 is a compact single-row deep groove ball bearing, measuring 9mm by 24mm by 7mm. Made from chrome steel, it handles radial loads up to 642 lbf and spins smoothly at speeds up to 32,000 RPM.

Its shielded design keeps dirt out while maintaining easy access for lubrication. The C2 radial clearance ensures smooth operation, even under varying temperatures from -30°C to 120°C.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. It’s ideal for small motors, fans, or appliances where reliable performance is needed.

Weighing just 14.7g, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it’s safe for various applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 609-2Z/C2EGWGVQ514
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C2
  • Bore Dia 9 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 24 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 642 lbf
  • Static Radial Load 260 lbf
  • Max Speed 32000 rpm
  • Weight 14.7 g
Single Row Deep Groove Ball Bearings 609-2Z/C2EGWGVQ514 dimension drawing
Download DWG Download PDF

Features

Performance Features of 609-2Z/C2EGWGVQ514 Bearing

609-2Z/C2EGWGVQ514 Bearing is designed with chrome steel rings and balls, offering strong radial load capacity.
Its dynamic radial load reaches 642 lbf, making it suitable for various applications.

The shielded design protects against contaminants, ensuring smooth operation.
With a maximum speed of 32,000 rpm, it balances efficiency and durability.

609-2Z/C2EGWGVQ514 Bearing operates in temperatures from -30°C to 120°C, adapting to different environments.
Its C2 radial clearance provides optimal performance under varying conditions.

Application

Common Applications of 609-2Z/C2EGWGVQ514 Bearing
609-2Z/C2EGWGVQ514 Bearing is widely used in small electric motors, such as those found in household appliances and power tools. Its shielded design helps keep contaminants out while maintaining smooth rotation.

In automation systems, 609-2Z/C2EGWGVQ514 Bearing fits well in compact robotic joints and conveyor rollers. The C2 radial clearance ensures reliable performance even with slight misalignments.

For consumer electronics like printers and cooling fans, 609-2Z/C2EGWGVQ514 Bearing offers quiet operation and long service life. The chrome steel construction provides durability in everyday use.

The metric sizing of 609-2Z/C2EGWGVQ514 Bearing makes it compatible with many European and Asian machinery designs. Its lightweight build is ideal for applications where space and weight are limited.
