Single Row Deep Groove Ball Bearings 6026-2RS1/C3

Single Row Deep Groove Ball Bearings 6026-2RS1/C3

The 6026-2RS1/C3 is a single-row deep groove ball bearing with a 130mm bore and 200mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 25179 lbf and operates smoothly at speeds up to 4300 RPM.

Its sealed design keeps out dust and moisture, extending its lifespan, while the C3 radial clearance allows for thermal expansion in demanding conditions. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or pumps where radial loads are predominant.

Weighing 3280g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6026-2RS1/C3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 130 mm
  • Bore Dia Tolerance -0.018mm to 0
  • Outer Dia 200 mm
  • Outer Dia Tolerance -0.020mm to 0
  • Width 33 mm
  • Width Tolerance -0.25mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 25179 lbf
  • Static Radial Load 22481 lbf
  • Max Speed 4300 rpm
  • Weight 3280 g
  • price（$） 104.553
Single Row Deep Groove Ball Bearings 6026-2RS1/C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6026-2RS1/C3 Bearing

6026-2RS1/C3 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 25179 lbf, ensuring reliable performance in various applications.

The sealed design of 6026-2RS1/C3 Bearing protects against dust and moisture, enhancing durability.
With a maximum speed of 4,300 rpm, it balances efficiency and long-term reliability.

6026-2RS1/C3 Bearing operates smoothly in temperatures ranging from -30°C to 120°C.
Its C3 radial clearance provides flexibility for thermal expansion in different working conditions.

The chrome steel cage ensures proper ball alignment, reducing friction and wear.
This design extends the bearing’s service life while maintaining consistent performance.

Installation is straightforward due to 6026-2RS1/C3 Bearing’s standardised dimensions.
Its robust construction minimises maintenance needs, lowering operational costs.

Application

Common Applications of 6026-2RS1/C3 Bearing
In industrial settings, 6026-2RS1/C3 Bearing is commonly used in heavy machinery like pumps and compressors, where its sealed design helps keep contaminants out. The C3 clearance ensures reliable performance even under varying thermal conditions.

Where Is 6026-2RS1/C3 Bearing Used?
You’ll often find 6026-2RS1/C3 Bearing in automotive applications such as wheel hubs and transmissions, thanks to its radial load capacity and durability. The chrome steel construction also makes it resistant to wear over time.

Built for Heavy-Duty Use: 6026-2RS1/C3 Bearing
This bearing excels in agricultural equipment, handling the demands of tractors and harvesters with ease. Its sealed design is particularly useful in dusty or wet environments.

Automotive vs Industrial: Applications of 6026-2RS1/C3 Bearing
In automotive systems, 6026-2RS1/C3 Bearing supports smooth rotation in drivetrains, while in industrial gearboxes, it ensures long-lasting performance under heavy loads. The metric sizing makes it versatile for various applications.

Ideal for Precision: 6026-2RS1/C3 Bearing
For conveyor systems and material handling equipment, 6026-2RS1/C3 Bearing offers consistent performance with minimal maintenance. The sealed design also reduces the need for frequent lubrication.
