Single Row Deep Groove Ball Bearings 6018-2Z

Single Row Deep Groove Ball Bearings 6018-2Z

The 6018-2Z is a single-row deep groove ball bearing with a 90mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 13601 lbf and operates smoothly at speeds up to 5000 RPM.

Its shielded design keeps grease in and contaminants out, extending its lifespan. The stainless steel cage adds durability, making it reliable for continuous use.

This bearing works well in temperatures from -30°C to 120°C, suitable for various industrial environments. It’s interchangeable with SKF models, offering a cost-effective replacement option.

Weighing 1.22kg, it’s robust yet manageable for its size. Ideal for applications like electric motors or pumps where radial load support is needed.

Compliant with RoHS and REACH standards, it’s a safe choice for environmentally conscious users. Easy to maintain and install, it’s a practical pick for engineers and maintenance teams.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6018-2Z
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 90 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 24 mm
  • Width Tolerance -0.2mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 13601 lbf
  • Static Radial Load 11240 lbf
  • Max Speed 5000 rpm
  • Weight 1.22 kg
  • price（$） 39.06
Single Row Deep Groove Ball Bearings 6018-2Z dimension drawing
Download DWG Download PDF

Features

Performance Features of 6018-2Z Bearing

6018-2Z Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 13601 lbf, ensuring reliable performance in various applications.

The shielded design of 6018-2Z Bearing protects against contaminants, extending its service life.
With a maximum speed of 5,000 rpm, it balances durability and efficiency for smooth operation.

6018-2Z Bearing operates effectively in temperatures ranging from -30° to 120°C.
Its stainless steel cage ensures stability and reduces wear during high-speed rotations.

The grease lubrication in 6018-2Z Bearing minimises maintenance needs while enhancing performance.
Its precise P6 tolerance class guarantees consistent and reliable operation over time.

Application

Industrial Uses of 6018-2Z Bearing
6018-2Z Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures it can handle radial loads efficiently in demanding environments.

Where Is 6018-2Z Bearing Used?
You’ll often find 6018-2Z Bearing in automotive applications such as alternators and wheel hubs, thanks to its reliable performance and grease lubrication. Its metric sizing makes it a versatile choice for various vehicle models.

Perfect Fit for Automation: 6018-2Z Bearing
In automated systems like conveyor belts, 6018-2Z Bearing provides smooth operation with minimal maintenance. The stainless steel cage adds durability, making it suitable for continuous use.

Medical vs Industrial: Where 6018-2Z Bearing Excels
While 6018-2Z Bearing is robust enough for industrial gear, it’s also precise enough for medical devices like lab equipment. The P6 tolerance class ensures consistent performance in both settings.

Light-Duty vs Heavy-Duty: Best Uses for 6018-2Z Bearing
For lighter tasks like household appliances, 6018-2Z Bearing offers quiet and efficient operation. In heavier industrial applications, its dynamic load capacity ensures long-lasting reliability.
