Single Row Deep Groove Ball Bearings 6018-2RS1/W64

Single Row Deep Groove Ball Bearings 6018-2RS1/W64

The 6018-2RS1/W64 is a single-row deep groove ball bearing with a 90mm bore and 140mm outer diameter, built from sturdy chrome steel. It manages radial loads up to 13084 lbf and runs smoothly at speeds up to 4800 RPM.

Sealed on both sides, it keeps dirt out and solid oil lubrication in, reducing maintenance needs. The chrome steel cage adds durability, making it a reliable choice for long-term use.

This bearing operates well in temperatures from -30°C to 120°C, suitable for various environments. It’s interchangeable with SKF models, offering flexibility for replacements.

Ideal for radial load applications like electric motors or pumps, where sealed protection is key. Weighing 1.16kg, it balances strength and practicality. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6018-2RS1/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 90 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 24 mm
  • Width Tolerance -0.200mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 13084 lbf
  • Static Radial Load 11173 lbf
  • Max Speed 4800 rpm
  • Weight 1163 g
  • price（$） 71.901
Single Row Deep Groove Ball Bearings 6018-2RS1/W64 dimension drawing
Download DWG Download PDF

Features

How Is 6018-2RS1/W64 Bearing Engineered for Reliability?

6018-2RS1/W64 Bearing features a sealed design with solid oil lubrication, ensuring consistent performance in various conditions.
Its chrome steel construction provides strong resistance to wear, making it suitable for radial load applications.

The bearing can handle dynamic radial loads up to 13084 lbf, offering reliable operation under stress.
With a maximum speed of 4,800 rpm, it balances efficiency and durability for long-term use.

6018-2RS1/W64 Bearing operates in temperatures from -30°C to 120°C, adapting to different environments.
Its sealed design reduces maintenance needs, making it a practical choice for many applications.

Application

Industrial Uses of 6018-2RS1/W64 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its sealed design keeps contaminants out. The solid oil lubrication ensures long service life even in dusty environments.

Where Is 6018-2RS1/W64 Bearing Used?
You’ll find it in automotive applications such as wheel hubs and alternators, thanks to its reliable radial load capacity. The chrome steel construction handles high temperatures well, making it suitable for engine compartments.

Perfect Fit for Automation: 6018-2RS1/W64 Bearing
In robotic arms and conveyor systems, this bearing offers smooth rotation with minimal maintenance. Its ABEC 1 tolerance provides consistent performance for precision movements.

Medical vs Industrial: Where 6018-2RS1/W64 Bearing Excels
While not for medical use, it shines in industrial equipment like gearboxes and compressors. The sealed design prevents lubricant leakage, crucial for clean manufacturing environments.

Consumer Electronics Applications of 6018-2RS1/W64 Bearing
Though large for most electronics, it works well in commercial appliances like industrial fans. The wide temperature range allows operation in various climate conditions.
