Single Row Deep Groove Ball Bearings 6013/DFC125

Single Row Deep Groove Ball Bearings 6013/DFC125

The 6013/DFC125 is a single-row deep groove ball bearing with a 65mm bore and 100mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 6857 lbf and operates smoothly at speeds up to 6700 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads are common.

Weighing 430g, it offers a balance of strength and lightness. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6013/DFC125
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 18 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6857 lbf
  • Static Radial Load 5665 lbf
  • Max Speed 6700 rpm
  • Weight 430 g
  • price（$） 63.594
Single Row Deep Groove Ball Bearings 6013/DFC125 dimension drawing
Download DWG Download PDF

Features

How Does 6013/DFC125 Bearing Reduce Friction?

6013/DFC125 Bearing features a single row deep groove design, optimised for smooth radial load handling.

Its chrome steel construction ensures durability and resistance to wear, even under continuous use.

With a dynamic radial load capacity of 6857 lbf, it performs reliably in various industrial applications.

The open seal type allows for easy maintenance, while the ABEC 1 tolerance ensures consistent performance.

Application

Ideal for Precision: 6013/DFC125 Bearing
The 6013/DFC125 Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design ensures smooth radial load handling. Its open seal type allows for easy lubrication, making it suitable for high-speed applications.

In automotive systems, 6013/DFC125 Bearing fits well in components such as alternators and wheel hubs, providing reliable performance under varying loads. The chrome steel construction offers durability, even in demanding driving conditions.

For automation equipment, 6013/DFC125 Bearing works efficiently in robotic arms and conveyor systems, thanks to its balanced load distribution. The ABEC 1 tolerance ensures consistent operation without compromising precision.

In household appliances like washing machines, 6013/DFC125 Bearing reduces noise and vibration during operation. Its compact size and metric measurements make it a versatile choice for various consumer devices.
