Single Row Deep Groove Ball Bearings 6011/C3W64F

The 6011/C3W64F is a single-row deep groove ball bearing with a 55mm bore and 90mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 6362 lbf and operates smoothly at speeds up to 7500 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage offers durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

With a C3 radial clearance, it’s suited for applications where slight expansion or misalignment might occur. Ideal for use in electric motors, pumps, or industrial gearboxes.

Weighing 373g, it’s a robust yet lightweight option. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6011/C3W64F
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Open
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No C3
Bore Dia 55 mm
Bore Dia Tolerance -0.015mm to 0
Outer Dia 90 mm
Outer Dia Tolerance -0.015mm to 0
Width 18 mm
Width Tolerance -0.150mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
Lubrication Soild Oil
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 6362 lbf
Static Radial Load 4766 lbf
Max Speed 7500 rpm
Weight 373 g
price（$） 18.369

Single Row Deep Groove Ball Bearings 6011/C3W64F dimension drawing

Download DWG Download PDF

Features

How Does 6011/C3W64F Bearing Reduce Friction?

6011/C3W64F Bearing features a single-row deep groove design, optimised for smooth radial load handling.
The chrome steel construction ensures durability while reducing friction during operation.

Solid oil lubrication maintains consistent performance, even in varying temperature conditions.
With a maximum speed of 7,500 rpm, it balances efficiency and reliability for diverse applications.

The C3 radial clearance allows for thermal expansion, enhancing performance under load.
Its open design simplifies maintenance, making it a practical choice for industrial use.

Application

Industrial Uses of 6011/C3W64F Bearing
6011/C3W64F Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The solid oil lubrication ensures long service life with minimal maintenance.

Where Is 6011/C3W64F Bearing Used?
You’ll often find 6011/C3W64F Bearing in automotive applications such as alternators and wheel hubs, thanks to its reliable performance under varying speeds. Its C3 radial clearance also accommodates thermal expansion in high-temperature environments.

Built for Heavy-Duty Use: 6011/C3W64F Bearing
6011/C3W64F Bearing excels in conveyor systems and agricultural equipment, where its chrome steel construction resists wear. The open seal design allows for easy inspection and re-lubrication when needed.

Automotive vs Industrial: Applications of 6011/C3W64F Bearing
In automotive settings, 6011/C3W64F Bearing supports smooth rotation in gearboxes, while in industrial settings, it’s ideal for fans and compressors. Its metric sizing ensures compatibility across various machinery types.

Perfect Fit for Automation: 6011/C3W64F Bearing
6011/C3W64F Bearing works well in robotic arms and automated assembly lines, where precision and durability are key. The solid oil lubrication reduces friction, ensuring consistent performance over time.
