Single Row Deep Groove Ball Bearings 6008

Single Row Deep Groove Ball Bearings 6008

The 6008 is a single-row deep groove ball bearing with a 40mm bore and 68mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 3754 lbf and spins smoothly at speeds up to 10,000 RPM.

Its open design simplifies lubrication, while the stainless steel cage enhances durability. The bearing operates reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a cost-effective replacement option. Perfect for applications like electric motors or pumps where radial loads are common.

Weighing just 192g, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6008
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No CN
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 68 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Required
  • REACH Compliant
  • Temperature Range -30° to 110 °C
  • Dynamic Radial Load 3754 lbf
  • Static Radial Load 2585 lbf
  • Max Speed 10000 rpm
  • Weight 192 g
  • price（$） 4.779
Single Row Deep Groove Ball Bearings 6008 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6008 Bearing

6008 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 3754 lbf.
Its single-row deep groove design ensures smooth operation, even at high speeds of 10,000 rpm.
The stainless steel cage maintains ball alignment, reducing friction and wear.
With a temperature range of -30° to 110°C, it performs reliably in various conditions.

Application

Industrial Uses of 6008 Bearing
The 6008 Bearing is commonly used in industrial machinery like pumps and electric motors, where its single-row design handles radial loads efficiently. Its open seal type simplifies lubrication, making maintenance straightforward for busy workshops.

What Makes 6008 Bearing a Preferred Choice?
In automotive applications, 6008 Bearing fits well in alternators and small gearboxes, thanks to its balanced performance and metric sizing. The chrome steel construction ensures durability even under continuous use.

Perfect Fit for Automation: 6008 Bearing
For automated systems like conveyor belts, 6008 Bearing offers reliable rotation with minimal friction. Its ABEC-1 tolerance provides adequate precision for most general-purpose applications.

Medical vs Industrial: Where 6008 Bearing Excels
While not typically used in medical devices, 6008 Bearing shines in light industrial equipment such as packaging machines. The stainless steel cage adds corrosion resistance for environments with occasional moisture exposure.

Where to Use 6008 Bearing
In household appliances like washing machines, 6008 Bearing supports rotating drums with quiet operation. The 40mm bore size makes it compatible with many standard appliance motor shafts.
