Single Row Deep Groove Ball Bearings 6008-2RSJEM GJN

The 6008-2RSJEM GJN is a sealed single-row deep groove ball bearing with a 40mm bore and 68mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 3754 lbf and spins smoothly at speeds up to 10,000 RPM.

Its sealed design keeps dirt out and grease in, making it low-maintenance for long-term use. The bearing operates well in temperatures from -30°C to 120°C, suitable for various environments.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for applications like electric motors or pumps where radial loads and moderate speeds are common.

Weighing just 192g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6008-2RSJEM GJN
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Sealed
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No CN
Bore Dia 40 mm
Bore Dia Tolerance -0.012mm to 0
Outer Dia 68 mm
Outer Dia Tolerance -0.013mm to 0
Width 15 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 3754 lbf
Static Radial Load 2585 lbf
Max Speed 10000 rpm
Weight 192 g
price（$） 8.451

Single Row Deep Groove Ball Bearings 6008-2RSJEM GJN dimension drawing

Download DWG Download PDF

Features

Performance Features of 6008-2RSJEM GJN Bearing

6008-2RSJEM GJN Bearing is designed with sealed construction, protecting it from dust and moisture.
Its chrome steel rings and balls provide reliable performance under radial loads up to 3754 lbf.

The bearing operates smoothly within a temperature range of -30°C to 120°C, suitable for various environments.
With a maximum speed of 10,000 rpm, it balances efficiency and durability.

6008-2RSJEM GJN Bearing’s compact design (40mm×68mm×15mm) makes it ideal for space-constrained applications.
Its sealed design reduces maintenance needs, ensuring long service life.

Application

Common Applications of 6008-2RSJEM GJN Bearing
6008-2RSJEM GJN Bearing is widely used in industrial machinery, such as conveyor systems and electric motors, where its sealed design helps keep out dust and debris. The chrome steel construction ensures durability in demanding environments.

In automotive applications, 6008-2RSJEM GJN Bearing can be found in components like alternators and water pumps, providing reliable performance under radial loads. Its metric sizing makes it compatible with a variety of vehicle models.

For household appliances, 6008-2RSJEM GJN Bearing is often used in washing machines and fans, where its smooth operation and low maintenance are appreciated. The sealed design also helps extend the bearing’s lifespan in these everyday applications.
